Crystal structure of 5-methyl-2-phenyl-1,3-dioxane-5-carboxylic acid, C12H14O4

  • Xian-You Yuan EMAIL logo , Guo-Kai Jia , Min Zhang and Lin Yuan
Published/Copyright: January 12, 2016
Download Article (PDF)
Become an author with De Gruyter Brill
Submit Manuscript Author Information
Zeitschrift für Kristallographie - New Crystal Structures
From the journal Zeitschrift für Kristallographie - New Crystal Structures Volume 231 Issue 1

Abstract

C12H14O4, monoclinic, C2/c, a = 32.6674(8) Å, b = 6.0061(2) Å, c = 23.2786(6) Å, α = 90°, β = 103.368(2)°, γ = 90°, V = 4443.6(2) Å3, Z = 16, Rgt(F) = 0.0459, wRref(F2) = 0.1412, T = 298(2) K.

CCDC no.:: 979108

Source of material

2,2-Bis(hydroxymethyl)propionic acid (0.5008 g, 3.7337 mmol), benzaldehyde (0.4351 g, 4.1000 mmol), cyclohexane (12 mL), N,N-dimethytformamide (2 mL) and p-toluene sulfonic acid (0.0281 g, 0.1630 mmol) were heated and stirred at 373 K for four hours. Then sodium bicarbonate (0.0151 g, 0.1793 mmol) was added to dissolve the residue after the solvent was evaporated under reduced pressure. The solution was washed with water (20 mL), and dried with anhydrous sodium sulfate. The resulting solution was filtered and evaporated, and the product was recrystallized from ethyl acetate to afford colorless crystals (0.6359 g, 2.8611 mmol; yield 76.63%; m. p. 462.3 K).

Table 1

Data collection and handling.

Crystal:Colorless, block, size 0.23×0.41×0.46 mm
Wavelength:Mo Kα radiation (0.71073 Å)
μ:1.00 cm−1
Diffractometer, scan mode:Bruker APEX-II CCD, φ and ω scans
2θmax:55°
N(hkl)measured, N(hkl)unique:17586, 5049
Criterion for Iobs, N(hkl)gt:Iobs > 2 σ(Iobs), 4119
N(param)refined:297
Programs:SHELXS-97 [7, 8]
Table 2

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å2).

AtomSitexyzUiso
H(2)8f0.2916(6)0.473(3)0.3740(8)0.073
H(16)8f0.2744(6)0.559(4)0.4621(8)0.078
H(1)8f0.06031.05320.14700.082
H(12)8f0.10910.87890.10570.084
H(11)8f0.14920.59240.15480.068
H(10)8f0.13370.25560.23670.043
H(9)8f0.23860.18930.26020.048
H(8)8f0.19530.06330.24480.048
H(14)8f0.05170.94140.23790.080
H(13)8f0.09170.65360.28790.064
H(4)8f0.15090.05910.32460.047
H(3)8f0.16910.18640.38390.047
H(6)8f0.2573−0.09090.34650.079
H(7)8f0.2114−0.18650.33000.079
H(5)8f0.2300−0.09400.39370.079
H(15)8f0.5200−0.05610.64420.083
H(17)8f0.47510.08700.69760.087
H(18)8f0.43120.38180.66110.070
H(26)8f0.44010.75030.58250.046
H(19)8f0.37970.93790.58950.049
H(25)8f0.33670.81010.57880.049
H(28)8f0.51890.08270.55170.075
H(27)8f0.47550.37700.51450.060
H(22)8f0.33251.13350.44710.075
H(21)8f0.35691.21040.51010.075
H(20)8f0.31121.11430.50080.075
H(24)8f0.39260.86160.44070.049
H(23)8f0.41570.97100.50070.049
Table 3

Atomic displacement parameters (Å2).

AtomSitexyzU11U22U33U12U13U23
O(1)8f0.18934(3)0.3912(2)0.24551(4)0.0400(5)0.0446(6)0.0323(5)0.0006(4)0.0098(4)0.0024(4)
O(2)8f0.27339(3)0.3853(2)0.34901(5)0.0436(6)0.0597(7)0.0444(6)−0.0171(5)0.0132(5)−0.0083(5)
O(3)8f0.23661(3)0.3879(2)0.41775(5)0.0466(6)0.0644(7)0.0405(6)−0.0149(5)0.0138(5)−0.0170(5)
O(4)8f0.14921(3)0.3867(2)0.31569(4)0.0386(5)0.0452(6)0.0332(5)0.0003(4)0.0097(4)0.0012(4)
O(5)8f0.38551(3)0.6119(2)0.58090(4)0.0391(5)0.0463(6)0.0367(5)−0.0026(4)0.0115(4)0.0016(4)
O(6)8f0.29423(4)0.6389(2)0.48855(5)0.0433(6)0.0640(7)0.0491(6)−0.0205(5)0.0121(5)−0.0083(5)
O(7)8f0.32670(3)0.6565(2)0.41481(5)0.0470(6)0.0646(7)0.0415(6)−0.0116(5)0.0101(5)−0.0153(5)
O(8)8f0.41766(3)0.6423(2)0.50202(4)0.0376(5)0.0466(6)0.0377(5)0.0000(4)0.0110(4)0.0022(4)
C(1)8f0.07647(6)0.9375(3)0.16692(9)0.065(1)0.0454(9)0.077(1)0.0000(8)−0.019(1)0.0060(9)
C(2)8f0.10546(6)0.8336(4)0.14244(9)0.065(1)0.072(1)0.067(1)−0.004(1)0.0017(9)0.028(1)
C(3)8f0.12947(6)0.6615(3)0.17187(8)0.0518(9)0.066(1)0.0506(9)0.0020(8)0.0103(7)0.0151(8)
C(4)8f0.12460(4)0.5904(2)0.22634(6)0.0360(7)0.0416(7)0.0375(7)−0.0058(6)−0.0016(5)−0.0026(6)
C(5)8f0.14822(4)0.3897(2)0.25489(6)0.0347(7)0.0414(7)0.0305(6)−0.0055(5)0.0038(5)−0.0030(5)
C(6)8f0.21027(5)0.1876(2)0.26667(6)0.0430(8)0.0416(7)0.0346(7)0.0026(6)0.0089(6)−0.0070(6)
C(7)8f0.21231(4)0.1572(2)0.33236(5)0.0378(7)0.0296(6)0.0343(7)−0.0035(5)0.0053(5)−0.0011(5)
C(8)8f0.24208(4)0.3246(2)0.36905(5)0.0345(6)0.0298(6)0.0315(6)−0.0001(5)0.0060(5)0.0023(5)
C(9)8f0.07134(6)0.8705(3)0.22111(9)0.059(1)0.062(1)0.067(1)0.0151(9)−0.0086(9)−0.0181(9)
C(10)8f0.09534(5)0.6975(3)0.25106(7)0.0518(9)0.059(1)0.0447(8)0.0068(8)0.0022(7)−0.0077(7)
C(11)8f0.16801(4)0.1847(2)0.34186(6)0.0401(7)0.0396(7)0.0365(7)−0.0091(6)0.0074(5)0.0030(5)
C(12)8f0.22935(6)−0.0753(3)0.35250(8)0.062(1)0.0319(7)0.060(1)0.0020(7)0.0059(8)0.0025(7)
C(13)8f0.50190(6)0.0598(3)0.6288(1)0.047(1)0.054(1)0.093(2)−0.0001(8)−0.0133(9)0.006(1)
C(14)8f0.47540(7)0.1471(4)0.66086(9)0.069(1)0.075(1)0.060(1)−0.003(1)−0.0104(9)0.0182(9)
C(15)8f0.44907(6)0.3241(3)0.63907(7)0.057(1)0.070(1)0.0454(9)0.0028(9)0.0034(7)0.0058(8)
C(16)8f0.44948(4)0.4149(3)0.58440(6)0.0330(7)0.0445(8)0.0428(8)−0.0077(6)−0.0010(6)−0.0013(6)
C(17)8f0.42429(4)0.6204(2)0.56379(6)0.0343(7)0.0433(8)0.0355(7)−0.0082(5)0.0045(5)−0.0027(5)
C(18)8f0.36336(5)0.8184(2)0.56731(6)0.0406(7)0.0440(8)0.0376(7)−0.0011(6)0.0093(6)−0.0078(6)
C(19)8f0.35547(4)0.8682(2)0.50144(6)0.0365(7)0.0328(6)0.0372(7)−0.0040(5)0.0075(5)−0.0027(5)
C(20)8f0.32389(4)0.7070(2)0.46566(6)0.0310(6)0.0321(6)0.0351(6)−0.0002(5)0.0066(5)−0.0011(5)
C(21)8f0.50156(5)0.1443(3)0.5740(1)0.0373(8)0.056(1)0.092(2)−0.0004(7)0.0089(8)−0.0078(9)
C(22)8f0.47550(5)0.3209(3)0.55177(8)0.0382(8)0.0523(9)0.060(1)−0.0072(7)0.0103(7)−0.0011(7)
C(23)8f0.33733(6)1.1036(2)0.48868(8)0.0557(9)0.0346(8)0.0589(9)−0.0004(6)0.0102(7)−0.0024(6)
C(24)8f0.39745(4)0.8494(2)0.48327(7)0.0371(7)0.0417(7)0.0427(7)−0.0091(6)0.0085(6)0.0041(6)

Discussion

The title compound was synthesized to be used as a reactive intermediate in organic syntheses [1]. This class of compounds has insecticidal as well as anti-foaming properties [2, 3]. The title compound 5-methyl-2-phenyl-1,3-dioxane-5-carboxylic acid was synthesized by the reaction of 2,2-Bis(hydroxymethyl) propionic acid with benzaldehyde and p-toluene sulfonic acid as catalyst. The crystal structures of some similar 1,3-dioxanes have been reported in the last years [4–6]. The literature known 4-chloro derivative [5] is isotypic to the title structure.

Corresponding author: Xian-You Yuan, Key Laboratory of Comprehensive Utilization of Advantage Plants Resources in Hunan South, Hunan University of Science and Engineering, Yongzhou Hunan 425199, P. R. China, e-mail:

Acknowledgements

This work was financially Supported by the Opening Project of Key Laboratory of Comprehensive Utilization of Advantage Plants Resources in Hunan South Hunan University of Science and Engineering (XNZW15C05), the Scientific Research Fund of Hunan Provincial Education Department (13A030, 14A058) and the Science and Technology Planning Project of Hunan Province (2015GK3037).

References

1. Marrian, S. F.: The chemical reactions of pentaerythritol and its derivatives. Chem. Rev. 43 (1948) 149–198.10.1021/cr60134a004Search in Google Scholar

2. Wang, G. W.; Yuan, X. Y.; Liu, Y. C.; Lei, X. G.: Preparation and properties of sulfonatesalt-type cleavablesurfactants with a 1,3-dioxane ring. J. Am. Oil Chem. Soc. 71 (1994) 727–730.10.1007/BF02541429Search in Google Scholar

3. Yuan, X. Y.; Yang, N. F.; Luo, H. A.; Liu, Y. J.: Synthesis of hetero diacetals and diketals of pentaerythritol under microwave irradiation. Chin. J. Org. Chem. 25 (2005) 1049–1052.Search in Google Scholar

4. Jia, G. K.; Yuan, L.; Zhang, M., Yuan, X. Y.: 2-(2-Chlorophenyl)-5-methyl-1,3-dioxane-5-carboxylic acid. Acta Crystallogr. E68 (2012) o2037.10.1107/S1600536812025019Search in Google Scholar PubMed PubMed Central

5. Zhang, M.; Jia, G. K.; Yuan, L.; Yuan, X. Y.: Crystal structure of 2-(4-chlorophenyl)-5-methyl-1,3-dioxane-5-carboxylic acid, C12H13ClO4. Z. Krist.-New Cryst. St. 228 (2013) 393–394.10.1524/ncrs.2013.0197Search in Google Scholar

6. Lin, Y.; Jiang, H. S.; Min, Z.: Crystal structure of 3, 3-dihydroxymethyl-1,6-dioxa-spiro[5.5]undecane, C11H20O4. Z. Krist. New Cryst. St. 227 (2012) 35–36.10.1524/ncrs.2012.0016Search in Google Scholar

7. Sheldrick, G. M.: SHELXS-97: Program for the Solution of Crystal Structures. University of Göttingen, Germany, 1997.Search in Google Scholar

8. Sheldrick, G. M.: SHELXL-97. Program for the Refinement of Crystal Structures. University of Göttingen, Germany, 1997.Search in Google Scholar

Received: 2014-11-13
Accepted: 2015-7-5
Published Online: 2016-1-12
Published in Print: 2016-3-1
