Crystal structure of 2-(4-Bromophenyl)-5-ethyl-1,3-dioxane-5-carboxylic acid, C13H15BrO4

  • Guo-Kai Jia , Lin Yuan , Min Zhang and Xian-You Yuan EMAIL logo
Published/Copyright: May 6, 2016
Download Article (PDF)
Become an author with De Gruyter Brill
Submit Manuscript Author Information
Zeitschrift für Kristallographie - New Crystal Structures
From the journal Zeitschrift für Kristallographie - New Crystal Structures Volume 231 Issue 3

Abstract

C13H15BrO4, monoclinic, P21/n (no. 14), a = 12.872(4) Å, b = 8.311(2) Å, c = 24.598(7) Å, β = 92.556(3)°, V = 2629.0(13) Å3, Z = 8, Rgt(F) = 0.0357, wRref(F2) = 0.0932, T = 296(2) K.

CCDC no.:: 1474710

Tables 1 and 2 contain details of the measurement method and a list of the atoms including atomic coordinates and displacement parameters.

Table 1:

Data collection and handling.

Crystal:Colorless blocks size 0.43 × 0.37 × 0.32 mm
Wavelength:Mo Kα radiation (0.71073 Å)
μ:31.31 cm−1
Diffractometer, scan mode: 2θmax, completenessBruker Apex-II CCD, φ and ω 53.4°, >99%,
N(hkl)measured, N(hkl)unique, Rint:27785, 4613, 0.033
Criterion for Iobs, N(hkl)gt:Iobs > 2 σ(Iobs), 3860
N(param)refined:328
Programs:Bruker programs [10], SHELX [11]
Table 2:

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å2).

AtomxyzUiso*/Ueq
Br21.61659(3)0.37502(5)0.133099(13)0.07253(15)
Br10.13350(2)0.72644(5)0.103814(16)0.07055(14)
C260.93542(17)0.3361(3)0.17355(9)0.0308(5)
C70.5835(2)0.8453(3)0.03997(10)0.0390(6)
H70.5815(2)0.9342(3)0.01378(10)0.0468(7)*
C130.83030(18)0.6693(3)0.07657(9)0.0321(5)
C141.4856(2)0.3238(3)0.16068(10)0.0421(6)
C230.96966(19)0.2004(3)0.21137(9)0.0346(5)
C100.7990(2)0.8034(3)0.03775(10)0.0364(5)
C40.4365(2)0.8849(3)0.10218(11)0.0468(7)
H40.4797(2)0.9511(3)0.12369(11)0.0562(8)*
C151.4800(2)0.2256(3)0.20544(11)0.0426(6)
H151.5403(2)0.1880(3)0.22342(11)0.0512(7)*
C221.0400(2)0.2626(3)0.25812(9)0.0387(6)
H22a1.0067(2)0.3533(3)0.27507(9)0.0464(7)*
H22b1.0495(2)0.1786(3)0.28529(9)0.0464(7)*
C211.03131(19)0.0744(3)0.18103(11)0.0387(6)
H21a1.04116(19)−0.0202(3)0.20375(11)0.0465(7)*
H21b0.99216(19)0.0426(3)0.14817(11)0.0465(7)*
C80.7218(2)0.7436(3)−0.00645(10)0.0410(6)
H8a0.7133(2)0.8250(3)−0.03454(10)0.0492(7)*
H8b0.7492(2)0.6474(3)−0.02297(10)0.0492(7)*
C90.7465(2)0.9393(3)0.06847(11)0.0433(6)
H9a0.7900(2)0.9693(3)0.10005(11)0.0519(7)*
H9b0.7388(2)1.0328(3)0.04503(11)0.0519(7)*
C110.8981(2)0.8668(3)0.01230(12)0.0509(7)
H11a0.8798(2)0.9603(3)−0.00970(12)0.0610(8)*
H11b0.9462(2)0.9020(3)0.04137(12)0.0610(8)*
C240.8704(2)0.1210(3)0.23209(11)0.0470(7)
H24a0.8293(2)0.0809(3)0.20095(11)0.0564(8)*
H24b0.8908(2)0.0289(3)0.25435(11)0.0564(8)*
C161.3832(2)0.1833(3)0.22332(10)0.0389(6)
H161.3787(2)0.1164(3)0.25341(10)0.0466(7)*
C201.18926(19)0.1839(3)0.21395(10)0.0372(6)
H201.19792(19)0.0926(3)0.23896(10)0.0446(7)*
C171.2934(2)0.2393(3)0.19706(10)0.0356(5)
C60.4088(2)0.7184(3)0.02404(10)0.0426(6)
H60.4334(2)0.6698(3)−0.00690(10)0.0511(7)*
C50.4749(2)0.8125(3)0.05655(10)0.0369(6)
C30.3356(2)0.8607(4)0.11619(12)0.0518(7)
H30.3109(2)0.9083(4)0.14731(12)0.0622(9)*
C20.3065(2)0.6960(3)0.03709(11)0.0462(7)
H20.2618(2)0.6349(3)0.01466(11)0.0554(8)*
C181.3019(2)0.3434(4)0.15336(11)0.0505(7)
H181.2420(2)0.3853(4)0.13617(11)0.0605(8)*
C191.3970(2)0.3851(4)0.13524(11)0.0529(7)
H191.4017(2)0.4547(4)0.10584(11)0.0635(9)*
C10.2716(2)0.7653(3)0.08369(11)0.0449(6)
C250.8023(2)0.2287(5)0.26484(14)0.0670(9)
H25a0.8404(7)0.264(2)0.2972(5)0.1004(14)*
H25b0.7815(16)0.3207(15)0.2434(4)0.1004(14)*
H25c0.7417(10)0.1702(10)0.2748(8)0.1004(14)*
C120.9531(3)0.7475(5)−0.02261(14)0.0690(10)
H12a0.9665(18)0.6505(12)−0.0023(4)0.1035(14)*
H12b0.9102(9)0.724(2)−0.0545(5)0.1035(14)*
H12c1.0178(10)0.7927(13)−0.0332(9)0.1035(14)*
O51.13900(13)0.3113(2)0.24020(7)0.0382(4)
O70.94367(15)0.4784(2)0.18635(7)0.0468(5)
O40.87465(16)0.7165(2)0.12221(7)0.0467(5)
H4a0.895(2)0.6378(3)0.1399(6)0.0701(7)*
O10.62330(14)0.7084(2)0.01460(7)0.0395(4)
O30.81976(15)0.5263(2)0.06459(7)0.0452(4)
O61.13047(13)0.1355(2)0.16701(7)0.0389(4)
O20.64706(13)0.8905(2)0.08546(7)0.0413(4)
O80.89221(15)0.2891(2)0.12772(7)0.0441(4)
H80.870(2)0.3674(4)0.1107(6)0.0662(7)*

Source of material

The mixture of 2,2-bis(hydroxymethyl)butyric acid (2.01 g, 13.50 mmol), 4-bromobenzaldehyde (4.43 g, 12.26 mmol), cyclohexane (20 mL), N,N-dimethylformamide (6 mL) and p-toluene sulfonic acid (0.13 g, 0.75 mmol) were refluxed for 3 h. After the mixture was cooled, sodium bicarbonate (0.06 g, 0.76 mmol) was added and stirred at room temperature for half an hour. The solvent was evaporated under reduced pressure and then ethyl acetate was added to dissolve the residue. Subsequently, the solution was washed with brine (20 ml×2) and water (20 ml×2), respectively. Then the organic layer was dried with anhydrous sodium sulfate, filtered. The product was recrystallized from n-hexane to afford colorless crystals (4.9 g, 9.98 mmol; yield 81.42 %).

Experimental details

Carbon-bound H atoms were placed in calculated positions (C—H 0.95 Å) and were included in the refinement in the riding model approximation, with U(H) set to 1.2Ueq(C). The H atoms of the methyl group were allowed to rotate with a fixed angle around the C—C bond to best fit the experimental electron density, with U(H) set to 1.5Ueq(O). The H atoms of the hydroxyl groups were refined using the HFIX 147 option in the SHELX program suite [11], with U(H) set to 1.5Ueq(O).

Discussion

Ketal compounds have a wide application in organic syntheses, because they are used as a protection of carbonyl groups or intermediates [1, 2]. In addtition, this type of compounds has insecticidal as well as anti-foaming properties [3, 4]. The crystal structures of some similar 1,3-dioxanes have been reported [5–9]. There are two crystallographically independent molecules in the asymmetric unit. They are pairwise hydrogen bonded to form dimeric units (cf. the figure). All bond lengths and angles are in the expected ranges.

Acknowledgements:

This work was financially supported by the Science and Technology Planning Project of Hunan Province (2015GK3037), the Scientific Research Fund of Hunan Provincial Education Department (14A058, 13A030).

References

1. Ono, D.; Yamamura, S.; Nakamura, M.: Preparation and properties of bis (sodium sulfate) types of cleavable surfactants derived from diethyl tartrate. J. Oleo. Sci. 54 (2005) 51–57.10.5650/jos.54.51Search in Google Scholar

2. Marrian, S. F.: The chemical reactions of pentaerythritol and its derivatives. Chem. Rev. 43 (1948) 149–198.10.1021/cr60134a004Search in Google Scholar PubMed

3. Wang, G. W.; Yuan, X. Y.; Liu, Y. C.; Lei, X.G.: Preparation and properties of sulfonate salt-type cleavable surfactants with a 1,3-dioxane ring. J. Am. Oil Chem. Soc. 71 (1994) 727–730.10.1007/BF02541429Search in Google Scholar

4. Yuan, X.Y.; Yang, N.F.; Luo, H.A.; Liu, Y.J.: Synthesis of hetero iacetals and diketals of pentaerythritol under microwave irradiation. Chin. J. Org. Chem. 25 (2005) 1049–1052.Search in Google Scholar

5. Yuan, L.; Ou, G. C.; Shi, J. H.; Zhang, M.; Yuan, X. Y.: Synthesis and crystal structure of 12-(2-chlorophenyl)-7,11,13,16-tetraoxaspiro [5.2.5.2]cetane. Chin. J. Org. Chem. 33 (2013) 1817–1821.10.6023/cjoc201303003Search in Google Scholar

6. Godard, A.; Thiebaud-Roux, S.; De Caro, P.; Vedrenne, E.; Mouloungui, Z.: New one-pot syntheses of ketals and acetals from oleic acid. Industrial Crops and Products. 52 (2014) 111–117.10.1016/j.indcrop.2013.10.011Search in Google Scholar

7. Jia, G. K.; Yuan, L.; Zhang, M.; Yuan, X. Y.: 2-(2-Chlorophenyl)-5-methyl-1,3-dioxane-5-carboxylic acid. Acta Crystallogr. E68 (2012) o2037.10.1107/S1600536812025019Search in Google Scholar PubMed PubMed Central

8. Zhang, M.; Jia, G. K.; Yuan, L.; Yuan, X. Y.: Crystal structure of 2- (4-chlorophenyl)-5-methyl-1, 3-dioxane-5-carboxylic acid, C12H13ClO4. Z. Kristallogr. NCS 228 (2013) 393–394.10.1524/ncrs.2013.0197Search in Google Scholar

9. Yuan, L.; Shi J. H.; Zhang M.: Crystal structure of 3, 3-dihydroxymethyl-1,6-dioxa-spiro[5.5]undecane, C11H20O4. Z. Kristallogr. NCS 227 (2012) 35–36.10.1524/ncrs.2012.0016Search in Google Scholar

10. Bruker: SAINT-Plus, SHELXTL and SADABS. Bruker AXS Inc., Madison, Wisconsin, USA, 2004.Search in Google Scholar

11. Sheldrick, G. M.: A short history of SHELX. Acta Crystallogr. A64 (2008) 112–122.10.1107/S0108767307043930Search in Google Scholar PubMed

Received: 2016-1-13
Accepted: 2016-4-17
Published Online: 2016-5-6
Published in Print: 2016-9-1

©2016 Guo-Kai Jia et al., published by De Gruyter.

This work is licensed under the Creative Commons Attribution-NonCommercial-NoDerivatives 3.0 License.
