Crystal structure of aquadichloridobis(1-((2-methyl-1H-imidazol-1-yl)methyl)-1H-benotriazole-κN)mercury(II), C22H24Cl2HgN10O

  • Hai-Yan Yang EMAIL logo
Published/Copyright: April 6, 2016
Download Article (PDF)
Become an author with De Gruyter Brill
Submit Manuscript Author Information
Zeitschrift für Kristallographie - New Crystal Structures
From the journal Zeitschrift für Kristallographie - New Crystal Structures Volume 231 Issue 3

Abstract

C22H24HgCl2N10O, monoclinic, C2/c (no. 15), a = 7.8093(3) Å, b = 23.167(3) Å, c = 14.0254(4) Å, β = 91.747(3)°, V = 2536.3(3) Å3, Z = 4, Rgt(F) = 0.0283, wRref(F2) = 0.0469, T = 291.15 K.

CCDC no.:: 1465342

Tables 1–3 contain details of the methods used and a list of the atoms including atomic coordinates and displacement parameters.

Table 1:

Data collection and handling.

Crystal:Colorless, block, size 0.16×0.18×0.21 mm
Wavelength:Mo Kα radiation (0.7107 Å)
μ:63.17 cm−1
Diffractometer, scan mode:Xcalibur, Eos, Gemini, ω scans
2θmax:52.74°
N(hkl)measured, N(hkl)unique:5736, 2596
Criterion for Iobs, N(hkl)gt:Iobs > 2 σ(Iobs), 2354
N(param)refined:169
Programs:SHELX [12]
Table 2:

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å2).

AtomSitexyzUiso
H(1)8f0.90480.27940.33240.040
H(2)8f1.00820.30540.49310.044
H(4A)8f0.36600.33720.43280.064
H(4B)8f0.44540.39430.47480.064
H(4C)8f0.42200.34050.54100.064
H(5A)8f0.65840.33980.64390.051
H(5B)8f0.85790.33190.64910.051
H(8)8f0.94400.58670.63170.054
H(9)8f1.23340.56620.62670.063
H(10)8f1.32970.47290.62150.065
H(11)8f1.14550.39410.62020.053
H(1A)8f0.552(6)0.563(2)0.717(3)0.08(2)
Table 3:

Fractional coordinates and atomic displacement parameters (Å2).

AtomSitexyzU11U22U33U12U13U23
Hg(1)4e0.50.29197(1)0.250.0333(1)0.0358(2)0.0236(1)0.0−0.00467(8)0.0
O(1)4e0.50.5841(3)0.750.056(3)0.036(4)0.063(3)0.0−0.001(3)0.0
Cl(1)8f0.2799(1)0.22651(6)0.33523(7)0.0470(6)0.0500(8)0.0356(5)−0.0120(6)0.0011(5)0.0097(5)
N(1)8f0.6692(4)0.3109(2)0.3721(2)0.031(2)0.029(2)0.024(2)−0.001(2)−0.005(1)0.001(2)
N(2)8f0.7606(4)0.3322(2)0.5158(2)0.040(2)0.027(2)0.025(2)−0.006(2)−0.007(1)0.001(2)
N(3)8f0.7857(4)0.4128(2)0.6240(2)0.040(2)0.035(2)0.031(2)−0.005(2)−0.004(1)−0.006(2)
N(4)8f0.6455(4)0.4476(2)0.6288(2)0.037(2)0.048(3)0.045(2)−0.002(2)−0.000(2)−0.012(2)
N(5)8f0.6958(4)0.5010(2)0.6313(2)0.042(2)0.044(3)0.050(2)0.007(2)−0.004(2)−0.012(2)
C(1)8f0.8403(5)0.2960(2)0.3799(3)0.031(2)0.027(3)0.040(2)0.003(2)−0.000(2)−0.001(2)
C(2)8f0.8971(5)0.3100(2)0.4685(3)0.034(2)0.030(3)0.045(2)−0.003(2)−0.010(2)0.000(2)
C(3)8f0.6221(4)0.3324(2)0.4544(2)0.035(2)0.025(3)0.026(2)−0.004(2)0.001(2)0.002(2)
C(4)8f0.4486(4)0.3529(2)0.4778(3)0.037(2)0.053(4)0.040(2)−0.004(2)0.006(2)−0.003(2)
C(5)8f0.7644(6)0.3511(2)0.6148(3)0.063(3)0.037(3)0.026(2)−0.008(3)−0.011(2)0.000(2)
C(6)8f0.9315(5)0.4457(2)0.6239(2)0.034(2)0.039(3)0.019(2)−0.005(2)−0.006(2)−0.004(2)
C(7)8f0.8720(5)0.5018(2)0.6282(2)0.036(2)0.035(3)0.025(2)−0.001(2)−0.003(2)−0.002(2)
C(8)8f0.9835(6)0.5489(2)0.6292(2)0.064(3)0.036(3)0.034(2)−0.006(3)−0.004(2)0.002(2)
C(9)8f1.1541(6)0.5362(3)0.6264(3)0.057(3)0.062(4)0.038(2)−0.026(3)−0.004(2)0.006(3)
C(10)8f1.2123(6)0.4792(3)0.6231(3)0.035(2)0.090(5)0.037(2)−0.009(3)−0.001(2)−0.006(3)
C(11)8f1.1054(5)0.4319(2)0.6220(3)0.041(2)0.058(4)0.035(2)0.012(3)−0.004(2)−0.007(2)

Source of material

A methanol solution (5 mL) of 1-((benzotriazol-1-yl)methyl)-1-H-1,3-(2-methyl-imdazol) (0.1 mmol) was added dropwise into a methanol solution (3 mL) of HgCl2 (0.05 mmol). The resulting solution was left at room temperature. After five days, colorless crystals were obtained and dried in air.

Experimental details

H atoms were generated geometrically, with C—H = 0.96, 0.97 and 0.93 Å for methyl, methylene and aromatic H, respectively, and constrained to ride their parent atoms with Uiso(H) = x times Ueq(C), where x = 1.5 for methyl H and x = 1.2 for all other H atoms.

Discussion

Multidentate N-heterocyclic compounds are often employed as ligands to produce polymeric networks due to their rich coordination sites and various coordination modes [1–6]. Recently, our group synthesized 1-[(benzotriazol-1-yl)methyl]-1-H-1,3-(2-methyl-imdazol), and studied its coordination behavior with transitional metal halides (such as ZnCl2, CoCl2, CdI2, HgBr2), obtaining a series of coordination compounds [7–10]. As part of our research, we reacted this N-heterocyclic compound with HgCl2, generating the title complex. Single crystal X-ray diffraction reveals that the title structure consists of mononuclear complex as shown in the figure [11, 12]. The Hg atom is five-coordinated by two N atoms of two 1-[(benzotriazol-1-yl)methyl]-1-H-1,3-(2-methyl-imdazol) ligands, two chlorido and one water ligand. The bond lengths of Hg-N and Hg-Cl are 2.175(3) Å and 2.6092(11) Å, respectively. The dihedral angle between the N1/Hg1/N1a and Cl1/Hg1/Cl1a planes is 92.3(2)°. In the crystal, the adjacent molecules are stacked through the aromatic π–π interactions (the centroid-centroid distances between imdazol rings is 3.531 Å, and the centroid-centroid distances between benzene rings are 3.578 Å and 3.590 Å.) [13].

Acknowledgements:

The authors are grateful to Zhongyuan University of Technology for financial support and thank Professor Hong-Wei Hou of Zhengzhou University for his help.

References

1. Weiss, D. T.; Haslinger, S.; Jandl, C.; Pothig, A.; Cokoja, M.; Kühn, F. E.: Application of open chain tetraimidazolium salts as precursors for the synthesis of silver tetra(NHC) complexes. Inorg. Chem. 54 (2015) 415–417.10.1021/ic502838xSearch in Google Scholar PubMed

2. Boselli, L.; Carraz, M.; Mazères, S.; Paloque, L.; González, G.; Benoit-Vical, F.; Valentin, A.; Hemmert, C.; Gornitzka, H.: Synthesis, structures, and biological studies of heterobimetallic Au(I)-Ru(II) complexes involving N-heterocyclic carbene-based multidentate ligands. Organometallics 34 (2015) 1046–1055.10.1021/om501158mSearch in Google Scholar

3. Yang, H.-Y.; Li, L.-K.; Wu, J.; Hou, H.-W.; Xiao, B.; Fan, Y.-T.: 3D coordination framework with uncommon two-fold interpenetrated 33.59.63-icy net and coordinated anion exchange. Chem. Eur. J. 15 (2009) 4049–4056.10.1002/chem.200802515Search in Google Scholar PubMed

4. Schweinfurth, D.; Krzystek, J.; Schapiro, I.; Demeshko, S.; Klein, J.; Telser, J.; Ozarowski, A.; Su, C.-Y.; Meyer, F.; Atanasov, M.; Neese, F.; Sarkar, B.: Electronic structures of octahedral Ni(II) complexes with 'click' derived triazole ligands: a combined structural, magnetometric, spectroscopic, and theoretical study. Inorg. Chem. 52 (2013) 6880–6892.10.1021/ic3026123Search in Google Scholar PubMed

5. Meng, X.-R.; Zhu, X.-Q.; Qi, Y.-F.; Hou, H.-W.; Fan, Y.-T.: Syntheses, structures and thermal stabilities of eight1-((benzotriazol-yl)methyl)-1H-1,3-imidazole complexes based on different anions. J. Mol. Struct. 934 (2009) 28–36.10.1016/j.molstruc.2009.06.015Search in Google Scholar

6. Cabeza, J. A.; Garcιa-Álvarez, P.; Pérez-Carreno, E.; Pruneda, V.: Synthesis and reactivity of cationic triruthenium clusters derived from 2-methyl- and 4-methylpyrimidines: from conventional cyclometalated ligands to novel types of N-heterocyclic carbenes. Chem. Eur. J. 19 (2013) 3426–3436.10.1002/chem.201203815Search in Google Scholar PubMed

7. Yang, H.-Y.; Li, Y.-H.; Chen, H.: Crystal structure of bis{1-[(benzotriazol-1-yl)methyl]-1-H-1,3-(2-methyl-imdazol)}diiodidoccadmium(II), [Cd(C11H11N5)2I2], C22H22CdI2N10. Z. Kristallogr. NCS 227 (2012) 527–528.10.1524/ncrs.2012.0256Search in Google Scholar

8. Yang, H.-Y.; Li, Y.-H.: Crystal structure of bis1-[(benzotriazol-1-yl)methyl]-1-H-1,3-(2-methyl-imdazol)dibromidomercury(II), [Hg(C11H11N5)2Br2], C22H22HgBr2N10. Z. Kristallogr. NCS 229 (2014) 83–84.10.1515/ncrs-2014-0035Search in Google Scholar

9. Yang, H.-Y.; Li, Y.-H.: Bis{1-[(1H-benzotriazol-1-yl)methyl]-2-methyl-1H-imdazole-κN3} dichloridozinc. Acta Crystallogr. E68 (2012) m819.10.1107/S1600536812022313Search in Google Scholar PubMed PubMed Central

10. Yang, H.-Y.; Li, Y.-H.; Zhao, Y.-M.: Bis{1-[(1H-benzotriazol-1-yl)methyl]-2-methyl-1H-imdazole-κN3} dichloridocobalt(II). Acta Crystallogr. E68 (2012) m948.10.1107/S1600536812026712Search in Google Scholar PubMed PubMed Central

11. Sheldrick, G. M.: A short history of SHELX. Acta Crystallogr. A64 (2008) 112–122.10.1107/S0108767307043930Search in Google Scholar PubMed

12. Dolomanov, O. V.; Bourhis, L. J.; Gildea, R. J.; Howard, J. A. K.; Puschmann, H.: OLEX2: a complete structure solution, refinement and analysis program. J. Appl. Crystallogr. (2009) 42 339–341.10.1107/S0021889808042726Search in Google Scholar

13. Janiak, C.: A critical account on π–π stacking in metal complexes with aromatic nitrogen-containing ligands. J. Chem. Soc., Dalton Trans. (2000) 3885–3896.10.1039/b003010oSearch in Google Scholar

Received: 2015-9-24
Accepted: 2016-3-14
Published Online: 2016-4-6
Published in Print: 2016-9-1

©2016 Hai-Yan Yang, published by De Gruyter.

This work is licensed under the Creative Commons Attribution-NonCommercial-NoDerivatives 3.0 License.
