The crystal structure of 6-methyl-3,20-dioxo-19-norpregna-4,6-dien-17-yl acetate–2,4-dihydroxybenzoic acid (1/1), C30H36O8

  • Xiao F. Chen ORCID logo , Peng Li , Juan Xu , Hui P. Wang und Li F. Ning EMAIL logo
Veröffentlicht/Copyright: 7. Dezember 2019
Artikel downloaden (PDF)
Veröffentlichen auch Sie bei De Gruyter Brill
Manuskript einreichen Informationen für Autor*innen
Zeitschrift für Kristallographie - New Crystal Structures
Aus der Zeitschrift Zeitschrift für Kristallographie - New Crystal Structures Band 235 Heft 2

Abstract

C30H36O8, monoclinic, P21 (no. 4), a = 10.899(2) Å, b = 11.002(2) Å, c = 11.847(2) Å, V = 1310.3(5) Å3, Z = 2, Rgt(F) = 0.0504, wRref(F2) = 0.1161, T = 163(2) K.

CCDC no.: 1955998

The molecular structure is shown in the figure. Table 1 contains crystallographic data and Table 2 contains the list of the atoms including atomic coordinates and displacement parameters.

Table 1:

Data collection and handling.

Crystal:Colorless block
Size:0.21 × 0.15 × 0.14 mm
Wavelength:Mo Kα radiation (0.71073 Å)
μ:0.10 mm−1
Diffractometer, scan mode:Rigaku AFC10\SATURN 724+, φ and ω
θmax, completeness:27.5°, 99%
N(hkl)measured, N(hkl)unique, Rint:9793, 5485, 0.040
Criterion for Iobs, N(hkl)gt:Iobs > 2 σ(Iobs), 5077
N(param)refined:347
Programs:CrystalClear [1], SHELX [2], Olex2 [3]
Table 2:

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å2).

AtomxyzUiso*/Ueq
O10.4456(2)0.5857(3)0.6440(2)0.0354(6)
O2−0.2240(2)0.6554(2)−0.4182(2)0.0402(6)
O30.0237(2)0.4474(2)−0.25088(18)0.0244(5)
O4−0.0277(2)0.4449(3)−0.4532(2)0.0369(6)
C10.3731(3)0.5896(3)0.5338(3)0.0277(7)
C20.2291(3)0.5548(4)0.4893(3)0.0367(9)
H2A0.1768820.6254860.4975340.044*
H2B0.2183320.4885170.5412590.044*
C30.1746(3)0.5131(4)0.3561(3)0.0337(8)
H3A0.2175700.4356360.3495940.040*
H3B0.0777110.4984190.3282260.040*
C40.1998(3)0.6077(3)0.2742(3)0.0240(6)
H40.1501120.6826740.2788920.029*
C50.3468(3)0.6411(3)0.3232(3)0.0235(6)
C60.4238(3)0.6308(3)0.4444(3)0.0264(7)
H60.5153310.6516580.4715140.032*
C70.4022(3)0.6894(3)0.2371(3)0.0236(6)
C80.5464(3)0.7252(4)0.2849(3)0.0319(8)
H8A0.5608840.7953870.3394760.048*
H8B0.5711650.7465050.2162080.048*
H8C0.6012530.6569920.3302720.048*
C90.3233(3)0.7047(3)0.1185(3)0.0243(7)
H90.3616690.7385330.0660170.029*
C100.1780(3)0.6715(3)0.0636(3)0.0209(6)
H100.1254890.7448690.0672770.025*
C110.1485(3)0.5702(3)0.1384(3)0.0213(6)
H110.1985680.4960190.1321670.026*
C12−0.0002(3)0.5394(3)0.0844(3)0.0242(6)
H12A−0.0512560.6107920.0929260.029*
H12B−0.0170410.4715970.1314670.029*
C13−0.0498(3)0.5032(3)−0.0517(3)0.0241(6)
H13A−0.0060750.426671−0.0596630.029*
H13B−0.1469560.488679−0.0836190.029*
C14−0.0196(3)0.6027(3)−0.1271(3)0.0209(6)
C150.1310(3)0.6312(3)−0.0696(3)0.0209(6)
H150.1781710.553317−0.0697960.025*
C16−0.1083(3)0.7139(3)−0.1358(3)0.0276(7)
H16A−0.0876580.747150−0.0537000.041*
H16B−0.2020200.689434−0.1715550.041*
H16C−0.0918430.776016−0.1875330.041*
C17−0.0332(3)0.5697(3)−0.2601(3)0.0236(6)
C180.0562(3)0.6640(3)−0.2876(3)0.0296(7)
H18A0.0014320.730654−0.3385930.036*
H18B0.1060180.625312−0.3323670.036*
C190.1537(3)0.7143(3)−0.1631(3)0.0241(6)
H19A0.2469030.709201−0.1567070.029*
H19B0.1328250.799824−0.1517750.029*
C20−0.1781(3)0.5679(3)−0.3531(3)0.0286(7)
C21−0.2632(3)0.4599(3)−0.3544(3)0.0320(7)
H21A−0.2894890.417979−0.4331970.048*
H21B−0.3428460.487299−0.3423860.048*
H21C−0.2126240.404046−0.2882830.048*
C220.0247(3)0.3969(3)−0.3536(3)0.0275(7)
C230.0966(4)0.2788(3)−0.3312(3)0.0345(8)
H23A0.0764130.232430−0.2698580.052*
H23B0.1925970.293731−0.3012610.052*
H23C0.0681950.232451−0.4076790.052*
O50.3391(2)0.4879(2)−0.20717(19)0.0322(6)
H50.3883890.516799−0.2401770.039*
O60.4346(2)0.3103(2)0.1775(2)0.0381(6)
H6A0.5030160.2999670.2413760.046*
O70.6691(3)0.3531(2)0.3512(2)0.0397(6)
O80.8101(2)0.4767(3)0.3105(2)0.0396(6)
H80.8461080.4509950.3826780.047*
C240.4277(3)0.4736(3)−0.0902(3)0.0268(7)
C250.3915(3)0.3989(3)−0.0141(3)0.0280(7)
H250.3078500.358704−0.0448420.034*
C260.4774(3)0.3826(3)0.1075(3)0.0263(7)
C270.6024(3)0.4398(3)0.1527(3)0.0270(7)
C280.6361(3)0.5136(3)0.0727(3)0.0313(7)
H280.7204060.5525720.1023240.038*
C290.5517(3)0.5318(3)−0.0470(3)0.0317(7)
H290.5768440.582602−0.0993260.038*
C300.6934(3)0.4187(3)0.2786(3)0.0316(8)

Source of material

6-Methyl-3,20-dioxo-19-norpregna-4,6-dien-17-yl acetate (50 mg; 0.135 mmol) and 2,4-dihydroxybenzoic (20.8 mg; 0.135 mmol) were added to a glass bottle; 2 mL methanol were then added to the bottle while stirring. The solution was heated to 60 °C, until it changed to clear, after that the solution was cooled at room temperature 25 °C. Crystals of the title compound were obstained by slow evaporation within 15 days.

Experimental details

The single crystal data collections were carried out on a Rigaku AFC-10/Saturn 724+CCD diffractometer with graphite-monochromated Mo Kα radiation (λ = 0.71073 Å) using the multi-scan technique. The structure was determined by direct methods using SHELXS-2014 and refined by full-matrix least-squares procedures on F2 with SHELXL-2018 [2]. All non-hydrogen atoms were obtained from the difference Fourier map and subjected to anisotropic refinement by full-matrix least-squares on F2. Hydrogen atoms were placed geometrically and treated as riding on the parent atoms.

Comment

6-Methyl-3,20-dioxo-19-norpregna-4,6-dien-17-yl acetate (NOMAC) belongs to a new generation of synthetic progestins that possess high affinities for progesterone receptor and low or no affinities for estrogen, androgen, glucocorticoid or mineralocorticoid receptors [4], [5], [6]. Because of the very low solubility across the physiological pH range, NOMAC requires micronization or nanomization to improve dissolution. Therefore, it is important to establish effective methods for enhancing the dissolution and bioavailability of NOMAC. It is agreed that co-crystals form a vital part of the solid-state toolbox for improving the properties of older medicines [7], [8], [9], [10]. To date, researchers have obtained many co-crystals of the steroids to improve their dissolution compared with the pure counterpart [11], [12]. Only one co-crystal of NOMAC has been reported to date to improve its dissolution profile about three to four times [12]. Therefore, increasing the dissolution of NOMAC through co-crystallization and consequently improving its bioavailability through the preparation of pharmaceutical acceptable co-crystals is of interest for the development of new dosage forms of NOMAC. The co-crystal structure of the title compound crystallized as colorless elongate prism-shaped crystals and was found to be a 1:1 co-crystal of NOMAC and 2,4-dihydroxybenzoic acid as revealed by the single crystal structure. The co-crystal crystallizes in the monoclinic P21 space group. The asymmetric unit consists of one NOMAC molecule and one 2,4-dihydroxybenzoic acid molecule. As expected, H-bonding interactions are dominant in the crystal structure. The 2,4-dihydroxybenzoic acid molecule blends into the 1D chain of NOMAC molecules, in which each 2,4-dihydroxybenzoic acid molecule links two NOMAC molecules through two intermolecular hydrogen bonds [O8–H8A⋯O4 (D⋯A distance of 2.694(3) Å, D—⋯A angle 157.2°; O1–H5⋯O5 (D⋯A distance of 2.683(4) Å, D—⋯A angle 161.6 °]. An intramolecular hydrogen bond is found in 2,4-dihydroxybenzoic acid [O6—H6A⋯O7 (D⋯A distance of 2.631(3) Å, D—⋯A angle 150.3°] in 2,4-dihydroxybenzoic acid molecule. Bond lengths and angels of all moieties are in the expected ranges [12], [13].

Acknowledgements

Our research is supported by Key national research and development programmes (No. 2016YFC1000901) and it is also supported by the innovation fund of National Research Institute for Family Planning (No. KYS [2019] GJM02).

References

1. Rigaku/MSC. CrystalClear. Rigaku/MSC Inc., The Woodlands, Texas, USA (2006).Suche in Google Scholar

2. Sheldrick, G. M.: Crystal structure refinement with SHELXL. Acta Crystallogr. C71 (2015) 3–8.10.1107/S2053229614024218Suche in Google Scholar PubMed PubMed Central

3. Dolomanov, O. V.; Bourhis, L. J.; Gildea, R. J.; Howard, J. A. K.; Puschmann, H.: OLEX2: a complete structure solution, refinement and analysis program. J. Appl. Crystallogr. 42 (2009) 339–341.10.1107/S0021889808042726Suche in Google Scholar

4. Sotruk, W. R.: New progestagens for contraceptive use. Hum. Reprod. Update 12 (2006) 169–178.10.1093/humupd/dmi046Suche in Google Scholar PubMed

5. Ruan, X.; Seeger, H.; Mueck, A. O.: The pharmacology of nomegestrol acetate. Maturitas 5 (2012) 345–353.10.1016/j.maturitas.2012.01.007Suche in Google Scholar PubMed

6. Mueck, A. O.; Sotruk-Ware, R.: Nomegestrol acetate, a novel progestogen for oral contraception. Steroids 76 (2011) 531–539.10.1016/j.steroids.2011.02.002Suche in Google Scholar PubMed

7. Wang, J.-R.; Ye, C.; Zhu, B.; Mei, X.-F.: Pharmaceutical cocrystals of the anti-tuberculosis drug pyrazinamide with dicarboxylic and tricarboxylic acids. CrystEngComm 17 (2015) 747–752.10.1039/C4CE02044HSuche in Google Scholar

8. Schulthesis, N.; Newman, A.: Pharmaceutical cocrystals and their physicochemical properties. Cryst. Growth Des. 9 (2009) 2950–2967.10.1021/cg900129fSuche in Google Scholar PubMed PubMed Central

9. Golob, M.; Perry, M.; Lusi, M. R.; Chierotti, I.; Voinovich, M. J.: Improving biopharmaceutical properties of vinpocetine through cocrystallization. J. Pharm. Sci. 12 (2016) 3626–3633.10.1016/j.xphs.2016.09.017Suche in Google Scholar PubMed

10. Chadha, K.; Karan, M.; Bhalla, R.; Vasisht, K.: Cocrystals of hesperetin: structure, pharmacokinetic and pharmacodynamic evaluation. Cryst. Growth Des. 17 (2017) 2386–2405.10.1021/acs.cgd.6b01769Suche in Google Scholar

11. Wang, J.-R.; Wang, X.-J.; Yang, Y.; Chen, X.-Y.; Mei, X.-F.: Solid-state characterization of 17-estradiol co-crystals presenting improved dissolution and bioavailability. CrystEngComm 8 (2016) 1–8.10.1039/C6CE00433DSuche in Google Scholar

12. Shikari, K.; Takata, N.; Takano, R.; Hayashi, Y.; Terada, K.: Dissolution improvement and mechanism of the improvement from co-crystallization of poorly water-soluble compounds. Pharm. Res. 25 (2008) 2581–2592.10.1007/s11095-008-9676-2Suche in Google Scholar PubMed

13. Combes, C.; Ratier, A.; Jaud, J.; Rodriguez, F.; Lanquetin, M.: Crystal growth and structure of a new hormonal derived compound. Int. J. Pharm. 248 (2002) 141–147.10.1016/S0378-5173(02)00423-4Suche in Google Scholar
