Crystal structure of diaqua-bis(1,10-phenanthroline-κ2N,N′)-bis(1,7-dicarba-closo-dodecaborane-1,7-dicarboxylato-κ3O,O′:O′′) dicobalt(II) — ethanol (1/1), C34H46B20Co2N4O11

  • Wang Xin , Kan Jinglan , Yang Liguo EMAIL logo , Niu Yongsheng , Song Haixiang , Tian Dayong and Gao Linna
Published/Copyright: December 7, 2018
Download Article (PDF)
Become an author with De Gruyter Brill
Submit Manuscript Author Information
Zeitschrift für Kristallographie - New Crystal Structures
From the journal Zeitschrift für Kristallographie - New Crystal Structures Volume 234 Issue 2

Abstract

C34H46B20Co2N4O11, triclinic, P1̄, a = 10.372(11) Å, b = 11.920(12) Å, c = 12.141(13) Å, α = 61.136(11)°, β = 85.699(10)°, γ = 67.497(11)°, V = 1203(2) Å3, Z = 1, Rgt(F) = 0.0410, wRref(F2) = 0.1065, T = 298(2) K.

CCDC no.: 1877127

Tables 1 and 2 contain details on crystal structure and measurement conditions and a list of the atoms including atomic coordinates and displacement parameters.

Table 1:

Data collection and handling.

Crystal:Red block
Size:0.40 × 0.31 × 0.16 mm
Wavelength:Mo Kα radiation (0.71073 Å)
μ:0.75 mm−1
Diffractometer, scan mode:SMART area detector, φ and ω
θmax, completeness:25.0°, 98%
N(hkl)measured, N(hkl)unique, Rint:6034, 4157, 0.018
Criterion for Iobs, N(hkl)gt:Iobs > 2 σ(Iobs), 3319
N(param)refined:337
Programs:Bruker [1], SHELX [2, 3]
Table 2:

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å2).

AtomxyzUiso*/Ueq
Co10.20159(4)0.32482(4)0.21053(4)0.03287(14)
N10.2664(2)0.1721(3)0.4015(2)0.0342(6)
N20.1107(2)0.1861(3)0.2255(2)0.0346(6)
O10.2987(2)0.4415(2)0.2216(2)0.0446(5)
O20.1234(2)0.6470(3)0.1675(3)0.0596(7)
O30.6177(2)0.7653(2)−0.13833(18)0.0415(5)
O40.7917(2)0.5849(2)0.00526(19)0.0428(5)
O50.0091(2)0.4720(2)0.1948(2)0.0434(5)
H5A0.03630.53830.17660.075(14)*
H5B−0.06530.50110.14610.063(12)*
O6−0.0273(15)0.6780(12)0.3823(10)0.187(5)
H60.01690.65310.33360.281*
C10.3437(3)0.1666(4)0.4883(3)0.0446(8)
H10.36880.24130.46560.054*
C20.3884(4)0.0550(4)0.6106(3)0.0553(9)
H20.44240.05530.66820.066*
C30.3524(4)−0.0560(4)0.6464(3)0.0537(9)
H30.3821−0.13190.72820.064*
C40.2701(3)−0.0542(3)0.5582(3)0.0399(7)
C50.2298(3)0.0625(3)0.4366(3)0.0308(6)
C60.1464(3)0.0698(3)0.3418(3)0.0314(6)
C70.1047(3)−0.0401(3)0.3725(3)0.0381(7)
C80.1469(4)−0.1575(3)0.4972(3)0.0473(8)
H80.1198−0.23050.51790.057*
C90.2256(4)−0.1647(3)0.5862(3)0.0500(8)
H90.2514−0.24250.66700.060*
C100.0226(3)−0.0258(4)0.2758(4)0.0494(8)
H10−0.0067−0.09610.29120.059*
C11−0.0138(4)0.0906(4)0.1600(4)0.0542(9)
H11−0.06850.10070.09590.065*
C120.0314(3)0.1950(4)0.1376(3)0.0481(8)
H120.00510.27450.05790.058*
C130.2486(3)0.5671(3)0.1925(3)0.0337(7)
C140.6689(3)0.6764(3)−0.0259(3)0.0314(6)
C150.026(2)0.5697(17)0.5090(13)0.172(7)
H15A−0.03880.59140.56480.207*
H15B0.11550.56540.53230.207*
C160.0445(17)0.4326(15)0.5285(12)0.136(6)
H16A0.11110.36070.60300.204*
H16B0.07890.42430.45610.204*
H16C−0.04420.42330.53930.204*
C170.3597(3)0.6264(3)0.1859(3)0.0280(6)
C180.5745(3)0.6800(3)0.0760(3)0.0282(6)
B10.4015(3)0.7151(3)0.0403(3)0.0293(7)
H1A0.35480.7337−0.04850.035*
B20.4485(4)0.8410(4)0.0452(3)0.0367(8)
H2A0.43430.9406−0.04040.044*
B30.5963(4)0.7488(4)0.1657(3)0.0373(8)
H3A0.67710.79020.15750.045*
B40.6426(3)0.5663(4)0.2329(3)0.0326(7)
H40.75240.49030.26780.039*
B50.5228(3)0.5449(3)0.1561(3)0.0293(7)
H50.55460.45400.14190.035*
B60.3046(4)0.8044(4)0.1204(3)0.0359(8)
H6A0.19480.88020.08490.043*
B70.4251(4)0.8255(4)0.1975(4)0.0445(9)
H70.39390.91650.21140.053*
B80.5445(4)0.6560(4)0.3136(4)0.0430(9)
H8A0.59050.63720.40270.052*
B90.4980(3)0.5300(4)0.3075(3)0.0347(8)
H9A0.51190.42960.39200.042*
B100.3640(4)0.6896(4)0.2854(3)0.0388(8)
H10A0.29190.69160.35620.047*

Source of material

Solvents, which were employed to prepare the title complex, were dried with appropriate drying agents and distilled under dinitrogen prior to use. Dichloromethane for preparation was directly used without further purification. The 1,7-dihydroxycarbonyl-1,7-dicarba-closo-dodecaborane was prepared according to the literature method [4]. Co(OAc)2⋅4H2O (49.8 mg, 0.2 mmol) was added to a suspension of 1,7-(COOH)2-1,7-C2B10H10 (0.10 mmol) and 1,10-phenanthroline (37.0 mg, 0.2 mmol) in chloromethane (10 mL). The mixture was stirred for 6 h at room temperature under the protection of dry nitrogen. Then a colourless solution formed. Single crystals were obtained by slow evaporation of a dichloromethane-n-hexane solution. (32.4 mg, 22.9%). m.p. 198–205 K. FTIR (KBr) v (cm−l): 2981, 2961, 2922, 2863; 2613, 2602, 2581, 2553.

Experimental details

All H atoms were placed geometrically and treated as riding on their parent atoms, with B—H 1.10, C—H 0.96, with Uiso(H) = 1.2Ueq(B), Uiso(H) = 1.5Ueq(C).

Comment

The coordination chemistry of functionalized carborates is one of the most dynamic areas of modern research. These boron clusters have several properties, such as three-dimensional aromaticity, chemical inertness, thermal stability, and a hydrophobic character. The best known and most investigated carboranes are the three 12-vertex ortho, meta, and para isomers C2B10H12, dicarbo-closo-dodecaboranes [5], [6]. The acidity of the terminal C—H bonds and the specific reactivity of the B—H groups in these boron clusters can be used to selectivity functionalize both vertices, thereby generating a series of building blocks to be used in synthesis of various kinds of supermolecular materials. The structure is similar with the one in reference [7].

The compound crystallizes with one formula unit in the unit cell. The figure depicts the complex showing the atom numbering. The environment of the Cu atom is six coordinated, in which three positions are occupied by the three oxygen atoms of the carborate, one position is occupied by the oxygen atom of water molecule, and the other two positions are occupied by two nitrogen atoms. The bond lengths of Co1—O1, Co1—O3, Co1—O4 and Co1—O5 are 2.059 Å, 2.135 Å, 2.310 Å and 2.038 Å, respectively. The bond lengths of Co1—N1 and Co1—N2 are 2.089 Å and 2.129 Å, respectively.

Acknowledgements

This work was supported by Henan science and technology project (Nos. 172102210161, 172102310166), the Key Scientific Research Projects of Colleges and Universities, Henan Province (Nos. 18A150020) and the Research Fund of Anyang Institute of Technology (Nos. YJJ2016014).

References

1. Bruker. SMART and SAINT for Windows NT Software Reference Manuals, Version 5.0. Bruker Analytical X-Ray Systems, Madison, WI (1997).Search in Google Scholar

2. Sheldrick, G. M.: SADABS, a software for empirical absorption correction. Göttingen, Germany (1997).Search in Google Scholar

3. SHELXL Reference Manual, version 5.1. Bruker Analytical X-Ray Systems, Madison, WI (1997).Search in Google Scholar

4. Das, N.; Stang, P. J.; Arif, A. M.; Campana, C. F.: Synthesis and structural characterization of carborane-containing neutral, self-assembled Pt-metallacycles. J. Org. Chem. 70 (2005) 10440–10446.10.1021/jo0517085Search in Google Scholar

5. Dou, D. M.; Zhang, D. P.; Li, D. C.; Wang, D. Q.: Two type skeleton heterobimetallic trinuclear Cu—Mo—S clusters containing closo carborane diphosphine ligand 1,2-bis(diphenylphosphino)-1,2-dicarba-closo-dodecaborane. Inorg. Chem. Commun. 9 (2006) 1109–1102.10.1016/j.inoche.2006.07.006Search in Google Scholar

6. Herberhold, M.; Jin, G. X.; Yan, H.; Milius, W.; Wrackmeyer, B.: 16- and 18-Electron Cp*Rh complexes with 1,2-dicarba-closo-dodecaborane(12)-1,2-dichalcogenolato ligands, as studied by multinuclear magnetic resonance. J. Organomet. Chem. 587 (1999) 252–257.10.1016/S0022-328X(99)00330-7Search in Google Scholar

7. Wang, H. W.; Li, D. C.; Hong, M.; Dou, J. M.: Syntheses, structural characterization and in vitro cytotoxic activity of triorganotin(IV) complexes based on 1,7-dihydroxycarbonyl-1,7-dicarba-closododecaborane ligand. J. Organomet. Chem. 740 (2013) 1–9.10.1016/j.jorganchem.2013.04.039Search in Google Scholar

Received: 2018-09-05
Accepted: 2018-11-05
Published Online: 2018-12-07
Published in Print: 2019-03-26

©2019 Wang Xin et al., published by De Gruyter, Berlin/Boston

This work is licensed under the Creative Commons Attribution 4.0 Public License.
