Crystal structure of 2, 3-bis((4-methylbenzoyl)oxy) succinic acid–N, N-dimethylformamide (1/1), C23H25NO9

  • Xianping Zhang , Sisi Feng ORCID logo EMAIL logo and Liping Lu
Published/Copyright: March 11, 2021
Download Article (PDF)
Become an author with De Gruyter Brill
Submit Manuscript Author Information
Zeitschrift für Kristallographie - New Crystal Structures
From the journal Zeitschrift für Kristallographie - New Crystal Structures Volume 236 Issue 3

Abstract

C23H25NO9, orthorhombic, P21212 (no. 18), a = 15.8641(6) Å, b = 11.1230(4) Å, c = 13.0925(5) Å, V = 2310.26(15) Å3, Z = 4, Rgt(F) = 0.0372, wRref(F2) = 0.0883, T = 298 K.

CCDC no.: 2053700

Table 1 contains crystallographic data and Table 2 contains the list of the atoms including atomic coordinates and displacement parameters.

Table 1:

Data collection and handling.

Crystal:Colourless block
Size:0.30 × 0.20 × 0.19 mm
Wavelength:Mo Kα radiation (0.71073 Å)
μ:0.10 mm−1
Diffractometer, scan mode:Bruker APEX-II, ω
θmax, completeness:25.0°, >99%
N(hkl)measured, N(hkl)unique, Rint:18108, 4085, 0.036
Criterion for Iobs, N(hkl)gt:Iobs > 2 σ(Iobs), 3477
N(param)refined:304
Programs:Bruker [1], SHELX [2], [3], [4]
Table 2:

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å2).

AtomxyzUiso*/Ueq
C10.62240 (16)0.4941 (3)0.19183 (19)0.0339 (6)
C20.53158 (15)0.4492 (2)0.19493 (18)0.0311 (6)
H20.52130.39740.13570.037*
C30.55159 (17)0.2672 (2)0.2854 (2)0.0383 (6)
C40.55833 (16)0.2144 (2)0.3877 (2)0.0374 (6)
C50.54128 (17)0.2783 (3)0.4762 (2)0.0453 (7)
H50.52090.35650.47190.054*
C60.5544 (2)0.2263 (3)0.5710 (2)0.0537 (8)
H60.54190.26990.62970.064*
C70.58575 (19)0.1107 (3)0.5796 (2)0.0526 (8)
C80.6015 (2)0.0476 (3)0.4913 (3)0.0578 (9)
H80.6215−0.03080.49600.069*
C90.5886 (2)0.0972 (3)0.3963 (3)0.0515 (8)
H90.60010.05250.33780.062*
C100.6043 (3)0.0555 (4)0.6826 (3)0.0763 (12)
H10A0.5796−0.02310.68610.115*
H10B0.58100.10530.73540.115*
H10C0.66420.04930.69170.115*
C110.92455 (18)−0.1348 (3)0.1047 (2)0.0389 (6)
C120.95257 (16)−0.0066 (2)0.12677 (18)0.0343 (6)
H120.92960.04570.07340.041*
C130.84854 (16)0.0968 (2)0.2255 (2)0.0343 (6)
C140.82866 (16)0.1350 (2)0.3310 (2)0.0346 (6)
C150.78141 (18)0.2390 (3)0.3457 (2)0.0431 (7)
H150.75940.28020.28990.052*
C160.76726 (18)0.2810 (3)0.4437 (2)0.0480 (7)
H160.73680.35170.45280.058*
C170.79725 (17)0.2206 (3)0.5282 (2)0.0455 (7)
C180.84065 (18)0.1135 (3)0.5126 (2)0.0474 (7)
H180.85880.06920.56870.057*
C190.85718 (19)0.0718 (3)0.4153 (2)0.0423 (7)
H190.88760.00110.40640.051*
C200.7859 (2)0.2703 (4)0.6343 (2)0.0674 (10)
H20A0.83530.31470.65360.101*
H20B0.77740.20530.68140.101*
H20C0.73770.32250.63560.101*
C210.8836 (4)0.4288 (4)0.8909 (3)0.1003 (17)
H21A0.84290.38320.85290.150*
H21B0.93120.37880.90640.150*
H21C0.90180.49640.85090.150*
C220.8190 (3)0.3800 (3)1.0582 (3)0.0857 (13)
H22A0.80840.41691.12320.129*
H22B0.86260.32081.06530.129*
H22C0.76840.34221.03400.129*
C230.83352 (18)0.5851 (3)1.0032 (2)0.0455 (7)
H230.85350.63940.95490.055*
N10.84570 (16)0.4713 (2)0.98548 (19)0.0502 (6)
O10.67437 (12)0.46938 (19)0.25434 (14)0.0492 (5)
O20.63548 (12)0.5615 (2)0.10986 (16)0.0503 (6)
H2A0.68580.57780.10550.076*
O30.51997 (11)0.38104 (15)0.28637 (13)0.0359 (4)
O40.57251 (17)0.2197 (2)0.20684 (15)0.0638 (7)
O50.96276 (16)−0.1973 (2)0.0466 (2)0.0787 (8)
O60.85445 (14)−0.1647 (2)0.14914 (19)0.0592 (6)
H6A0.8361−0.22650.12330.089*
O70.92193 (11)0.03483 (16)0.22349 (13)0.0362 (4)
O80.80891 (14)0.1204 (2)0.14990 (15)0.0556 (6)
O90.79729 (13)0.62689 (18)1.07963 (16)0.0478 (5)

Source of material

All chemicals were of analytical reagent grade and used without further purification. La(NO3)3⋅6H2O (0.06 mmol) was dissolved in the mixture of N,N-dimethylformamide (DMF) (2 mL) and water (2 mL), and (2S, 3S)-2,3-bis((4-methylbenzoyl)oxy) succinic acid (0.09 mmol) was dissolved in water (2 mL), then mixed together adjusting the pH of the solution to 5 with KOH (1 M), then stayed the solution at 298 K in a tube. Colorless prismatic crystals of the title compound were obtained after a few weeks in 20% yield. Surprisingly the La ions are not included.

Experimental details

Coordinates of hydrogen atoms were constrained using a riding model. Their Uiso values were set to 1.2Ueq of the parent atoms.

Comment

Tartaric acid is one of the common chiral and small molecules, which is relatively cheap and easy to obtain. Employing this chiral organic molecule and related deprotonated anions as ligands, novel and chiral metal organic complexes can be constructed. Compared with tartaric acid, tartaric acid derivatives have more functional groups, which construct novel and multifunctional metal organic complexes [5], [ 6]. Here, the chiral tartaric acid derivative, named (2S, 3S)-2, 3-bis((4-methylbenzoyl)oxy) succinic acid, was chosen. It is a versatile ligand with various coordination modes, such as monodentate, chelated bidentate, bridge bidentate, etc. So the complexes constructed from this chiral ligand have diverse structures like chain, layer and network, and significant potential applications in optics, electricity, magnetism, etc. [6], [7], [8].

We anticipated to build La-organic frameworks using (2S, 3S)-2, 3-bis((4-methylbenzoyl)oxy) succinic acid, but we got the title compound unexpectedly. The asymmetric unit of the title complex contains one 2, 3-bis((4-methylbenzoyl)oxy) succinic acid molecule (distributed over two halfs, located around twofold axis) and one N,N-dimethylformamide solvent. One C2-symmetric title molecule is shown in the figure. Bond lengths and angles are all in the expected ranges [9], [10]. There are abundant weak interactions in the structure. Firstly, a variety of weak hydrogen bonds exist. The N,N-dimethylformamide and 2, 3-bis((4-methylbenzoyl)oxy) succinic acid were linked together through O2—H6A···O9i ((i) x, y-1, z-1) and O6—H2···O9ii ((ii) x, y, z-1) hydrogen bonds. Secondly, π···π interactions between aromatic rings are also contained in the structure. The geometry analysis shows a face-to-face alignment of the aromatic-aromatic rings. The distance between Cg1 ring (C4–C9) and Cg2 (C14–C19) ring is 3.8856(13) Å, and the dihedral angel between two rings in two planes is 3.4°.

Corresponding authors: Sisi Feng and Liping Lu, Institute of Molecular Science, Key Laboratory of Chemical Biology and Molecular Engineering of the Education Ministry, Shanxi University, Taiyuan, Shanxi 030006, People’s Republic of China, E-mail: (S. Feng), (L. Lu)

Funding source: Natural Science Foundation of China

Award Identifier / Grant number: 21671124

Funding source: Scientific Instrument Center of Shanxi University of China

  1. Author contribution: All the authors have accepted responsibility for the entire content of this submitted manuscript and approved submission.

  2. Research funding: The Natural Science Foundation of China (Grant No 21671124) and the Scientific Instrument Center of Shanxi University of China.

  3. Conflict of interest statement: The authors declare no conflicts of interest regarding this article.

References

1. Bruker. APEX2, SAINT and SADABS; Bruker AXS Inc.: Madison, WI, USA, 2009.Search in Google Scholar

2. Sheldrick, G. M. SHELXT-Integrated space-group and crystal-structure determination. Acta Crystallogr. 2015, A71, 3–8; https://doi.org/10.1107/s2053273314026370.Search in Google Scholar

3. Sheldrick, G. M. Crystal structure refinement with SHELXL. Acta Crystallogr. 2015, C71, 3–8; https://doi.org/10.1107/s2053229614024218.Search in Google Scholar

4. Sheldrick, G. M. A short history of SHELX. Acta Crystallogr. 2008, A64, 112–122; https://doi.org/10.1107/s0108767307043930.Search in Google Scholar

5. Hasan, M., Zaman, M., Peshkov, A. A., Amire, N., Les, A., Nechaev, A. A., Wang, Y., Kashtanov, S., Van der Eycken, E. V., Pereshivko, O. P., Peshkov, V. A. Four–component one–pot process involving passerini reaction followed by Aldol addition and transesterification. Eur. J. Org Chem. 2020, 2020, 3378–3389; https://doi.org/10.1002/ejoc.202000015.Search in Google Scholar

6. Han, M. R., Li, S., Ma, L., Yao, B., Feng, S.-S., Zhu, M. Luminescent and magnetic bifunctional coordination complex based on a chiral tartaric acid derivative and europium. Acta Crystallogr. 2019, C75, 1220–1227; https://doi.org/10.1107/s205322961901060x.Search in Google Scholar

7. Howell, B. A., Sun, W. Biobased flame retardants from tartaric acid and derivatives. Polym. Degrad. Stabil. 2018, 157, 199–211; https://doi.org/10.1016/j.polymdegradstab.2018.10.006.Search in Google Scholar

8. Liao, J., Peng, X., Zhang, J., Yu, K., Cui, X., Zhu, J., Deng, J. Facile resolution of racemic terbutaline and a study of molecular recognition through chiral supramolecules based on enantiodifferentiating self-assembly. Org. Biomol. Chem. 2003, 1, 1080–1085; https://doi.org/10.1039/b211327a.Search in Google Scholar

9. Bernauer, K., Gretillat, F., Stoeckli-Evans, H., Warmuth, R. Structure and highly stereoselective formation of 1:2 methal-to-ligand complexes with triamine 2,6-bis(pyrolidin-2-yl)pyridine. meso-[2,6-bis(pyrrolidin- 2yl)pyridine]nickel(II)(meso-[Ni(bpp)2]2+), a metal complex with S4 symmetry. Helv. Chim. Acta 1993, 76, 545–556; https://doi.org/10.1002/hlca.19930760136.Search in Google Scholar

10. Tang, L.-D., Duan, G.-Y., Zhang, D.-T., Wang, J.-W. 2,3-Di-p-toluoyl-(2R,3R)-tartaric acid ethyl acetate solvate. Acta Crystallogr. 2006, E62, o1685–o1686; https://doi.org/10.1107/s1600536806011469.Search in Google Scholar
