The metaverse has captured significant attention as it provides a virtual realm that cannot be experienced in the physical world. Programmable optical holograms, integral components of the metaverse, allow users to access diverse information without needing external equipment. Meta-devices composed of artificially customized nano-antennas are excellent candidates for programmable optical holograms due to their compact footprint and flexible electromagnetic manipulation. Programmable optical meta-holograms can dynamically alter reconstructed images in real-time by directly modulating the optical properties of the metasurface or by modifying the incident light. Information can be encoded across multiple channels and freely selected through switchable functionality. These advantages will broaden the range of virtual scenarios in the metaverse, facilitating further development and practical applications. This review concentrates on recent advancements in the fundamentals and applications of programmable optical meta-holograms. We aim to provide readers with general knowledge and potential inspiration for applying programmable optical meta-holograms, both intrinsic and external ways, into the metaverse for better performance. An outlook and perspective on the challenges and prospects in these rapidly growing research areas are provided.

Photonic crystals are periodic dielectric structures that possess a wealth of physical characteristics. Owing to the unique way they interact with the light, they provide new degrees of freedom to precisely modulate the electromagnetic fields, and have received extensive research in both academia and industry. At the same time, fueled by the advances in computer science, inverse design strategies are gradually being used to efficiently produce on-demand devices in various domains. As a result, the interdisciplinary area combining photonic crystals and inverse design emerges and flourishes. Here, we review the recent progress for the application of inverse design in photonic crystals. We start with a brief introduction of the background, then mainly discuss the optimizations of various physical properties of photonic crystals, from eigenproperties to response-based properties, and end up with an outlook for the future directions. Throughout the paper, we emphasize some insightful works and their design algorithms, and aim to give a guidance for readers in this emerging field.

In recent years, metasurface, as a representative of micro- and nano-optics, have demonstrated a powerful ability to manipulate light, which can modulate a variety of physical parameters, such as wavelength, phase, and amplitude, to achieve various functions and substantially improve the performance of conventional optical components and systems. Artificial Intelligence (AI) is an emerging strong and effective computational tool that has been rapidly integrated into the study of physical sciences over the decades and has played an important role in the study of metasurface. This review starts with a brief introduction to the basics and then describes cases where AI and metasurface research have converged: from AI-assisted design of metasurface elements up to advanced optical systems based on metasurface. We demonstrate the advanced computational power of AI, as well as its ability to extract and analyze a wide range of optical information, and analyze the limitations of the available research resources. Finally conclude by presenting the challenges posed by the convergence of disciplines.

Thermal emission caused by the thermal motion of the charged particles is commonly broadband, un-polarized, and incoherent, like a melting pot of electromagnetic waves, which makes it unsuitable for infrared applications in many cases requiring specific thermal emission properties. Metasurfaces, characterized by two-dimensional subwavelength artificial nanostructures, have been extensively investigated for their flexibility in tuning optical properties, which provide an ideal platform for shaping thermal emission. Recently, remarkable progress was achieved not only in tuning thermal emission in multiple degrees of freedom, such as wavelength, polarization, radiation angle, coherence, and so on but also in applications of compact and integrated optical devices. Here, we review the recent advances in the regulation of thermal emission through metasurfaces and corresponding infrared applications, such as infrared sensing, radiative cooling, and thermophotovoltaic devices.

Snapshot spectral imaging technology enables the capture of complete spectral information of objects in an extremely short period of time, offering wide-ranging applications in fields requiring dynamic observations such as environmental monitoring, medical diagnostics, and industrial inspection. In the past decades, snapshot spectral imaging has made remarkable breakthroughs with the emergence of new computational theories and optical components. From the early days of using various spatial-spectral data mapping methods, they have evolved to later attempts to encode various dimensions of light, such as amplitude, phase, and wavelength, and then computationally reconstruct them. This review focuses on a systematic presentation of the system architecture and mathematical modeling of these snapshot spectral imaging techniques. In addition, the introduction of metasurfaces expands the modulation of spatial-spectral data and brings advantages such as system size reduction, which has become a research hotspot in recent years and is regarded as the key to the next-generation snapshot spectral imaging techniques. This paper provides a systematic overview of the applications of metasurfaces in snapshot spectral imaging and provides an outlook on future directions and research priorities.

Probing the time evolution of the terahertz electric field within subwavelength dimensions plays a crucial role in observing the nanoscale lightwave interactions with fundamental excitations in condensed-matter systems and in artificial structures, such as metamaterials. Here, we propose a novel probing method for measuring terahertz electric potentials across nanogaps using a combination of optical and terahertz pulse excitations. To achieve this, we employ ring-shaped nanogaps that enclose a metallic island, allowing us to capture tunneling charges when subjected to terahertz electromagnetic pulse illumination. By controlling and manipulating the terahertz tunneling charges through a focused optical gate pulse, we can obtain the terahertz potential strength as a function of spatial coordinates and time delays between pulses. To accurately quantify the time evolution of terahertz electric potential across quantum barriers, we carefully calibrate the recorded nonlinear tunneling current. Its on-resonance and off-resonance behaviors are also discussed, providing valuable insights into the antenna’s characteristics and performance.

The ever-growing demand for miniaturized optical systems presents a significant challenge in revolutionizing their core element – the varifocal lens. Recent advancements in ultra-thin, tunable metasurface optics have introduced new approaches to achieving zoom imaging. However, current varifocal metalens have faced challenges such as low focusing efficiency, limited tunability, and complicated designs. Here, we employ the high-contrast transmit arrays (HCTA) structures to design and fabricate a polarization-independent, single-layer flexible metalens that operates at a wavelength of 940 nm. Using a uniform stretching system, we characterized its optical performance to achieve over 60 % focusing efficiency within a 0 %–25 % stretch range, while the focal length changes align with theoretical predictions. Furthermore, our research also successfully demonstrated the capacity of a metalens with a numerical aperture (NA) of 0.5 to efficiently adjust imaging magnification within a 2× range, achieving imaging results that approach the diffraction limit. This research offers promising prospects for the practical use of compact and miniaturized optoelectronic devices in fields like photography, mixed reality, microscopy, and biomedical imaging.

Recently, significant efforts have been devoted to guaranteeing high-quality communication services in fast-moving scenes, such as high-speed trains. The challenges lie in the Doppler effect that shifts the frequency of the transmitted signal. To this end, the recent emergence of spatiotemporal metasurfaces offers a promising solution, which can manipulate electromagnetic waves in time and space domain while being lightweight and cost-effective. Here we introduce deep learning-assisted spatiotemporal metasurfaces to automatically and adaptively neutralize Doppler effect in fast-moving situations. A tandem neural network is used to establish a rapid connection between on-site targets and time-varying series of spatiotemporal metasurfaces, endowing the capability of on-demand beamforming with Doppler effects offset. Moreover, oblique incidence problems are also studied in practice, which can be used for relieving multipath effect. In the microwave experiment, we fabricate the intelligent spatiotemporal metasurfaces and demonstrate the potential to fulfill Doppler-offset beamforming under oblique incidence.

Metasurfaces are artificial thin materials that achieve optical thickness through thin geometrical structure. This feature of metasurfaces results in unprecedented benefits for enhancing the performance of optoelectronic devices. In this study, we report that this metasurface feature is also essential to drive photo-thermoelectric conversion, which requires the accumulation of thermal energy and effective heat conduction. For example, a metasurface-attached thermoelectric device placed in an environment with uniform thermal radiation generates an output voltage by gathering the thermal energies existing in the environment and creating an additional thermal gradient across the thermoelectric element. In contrast, when a 100-μm-thick-carbon-black-coated electrode was used instead of the metasurface, the device showed lower thermoelectric performance than that of the metasurface-attached device although carbon black exhibits higher infrared absorption than the metasurface. These results indicate that metasurface characteristics of optical thickness and thin geometrical structure for achieving the high thermal conductance are essential in enhancing the performance of photo-thermoelectric devices in terms of the effective collection of thermal energies and conduction of local heating.

High-Q resonances in metasurfaces, stemming from symmetry-protected bound states in the continuum (BICs), have proven to be effective for achieving high-performance optical devices. However, the properties associated with symmetry-protected BICs are inherently limited, as even a slight variation in the asymmetry parameter leads to a noticeable shift in the resonance location. Herein, we introduce the concept of relative shift–induced quasi-BICs (QBICs) within dimerized silicon (Si) meta-lattices (DSMs), which can be excited when a nonzero relative shift occurs, a result of in-plane inversion symmetry breaking and Brillouin zone folding within the structure. These QBICs have resonance locations that remain insensitive to variations in asymmetrical parameters. Additionally, their Q-factors can be flexibly tuned, benefiting from the inverse square dependence on asymmetrical parameters. In experiment, six DSMs with different relative shifts are fabricated and the asymmetry parameter-insensitive resonant modes under two orthogonal polarization states are experimentally observed in the optical communication waveband. Our results offer unique opportunities for constructing high-Q resonators with enhanced performances, which can be applied in various optical fields.

Collimated flat-top beam shapers primarily consisting of freeform lenses have a wide range of applications and pose challenges in terms of processing and integration when the diameter is less than millimeters. Metasurfaces represent a promising solution to planarize optics, can mimic any surface curvature without additional fabrication difficulty, and are suitable for flat-top optics. The conventional metasurface design approach relies on imparting the required phase using meta-atoms and encounters challenges in amplitude modulation due to near-field coupling and varying transmittances among meta-atoms with different phases, making the design of flat-top beam shapers difficult. In this paper, we propose a complex-amplitude constraint Gerchberg–Saxton algorithm for designing a collimated flat-top beam shaper metasurface doublet, which avoids the influence of strong near-field coupling on the amplitude distribution and simultaneously considers the amplitude-phase characteristics of the meta-atoms. A collimated flat-top beam with exceptional homogeneity U p of approximately 0.01, a wavefront error less than 0.1 λ , and a transmittance higher than 86 % is experimentally obtained, comparable to commercial products based on freeform lenses. A collimated flat-top beam shaper metasurface doublet for generating flat-top beam is introduced, promoting efficient integration with laser systems.

Sharp-bending waveguide is a key element for ultra-compact and densely integrated photonic devices, which is promising to enlarge the capability of modern information processing in a single chip. Topological photonics manifest the nature of robust propagation against sharp bending and such robustness has been experimentally demonstrated in topological integrated interfaces. It is important to quantify the bending loss of topological interface but has remained exclusive. In this work, we report on the characterization of sharp-bending robustness in the integrated topological interface of valley photonic crystals (VPCs) by experimentally quantifying the ultralow bending loss. The VPCs are designed on a standard silicon-on-insulator platform with the inversion-symmetry broken in honeycomb lattice, and four types of topological interfaces can be constructed by two topologically-distinct VPCs. As one of the representative cases, zigzag-AA interface is applied to demonstrate the robust propagation along sharp bending. In experiment, we fabricate a series of VPC interfaces with different turn number and the same transmission distance, which perform the ultralow bending loss less than 0.02 dB per 120-deg turning. Furthermore, we experimentally characterize the propagation loss in the integrated interfaces. Our approach not only shows the ability of VPC topological interfaces to suppress backscattering stemming from sharp bending, but also paves the way for topological nanophotonic dense integration.

Topological photonic crystals have great potential in the application of on-chip integrated optical communication devices. Here, we successfully construct the on-chip transmissible topological edge states using one-dimensional Su–Schrieffer–Heeger (SSH) photonic crystals with defect cavities on silicon-on-insulator slab. Different coupling strengths between the lateral modes and diagonal modes in photonic crystal defect cavities are used to construct the SSH model. Furthermore, two photonic SSH-cavity configurations, called α and β configurations, are designed to demonstrate the topological edge states. Leveraging the capabilities of photonic crystal transverse electric modes with on-chip transmission, we introduced a waveguide to excite a boundary defect cavity and found that the transmission peak of light, corresponding to the topological edge state, can be received in another boundary defect cavity, which is caused by the tunnel effect. Moreover, the position of this peak experiences a blue shift as the defect cavity size increases. Therefore, by tuning the size of the SSH defect cavity, on-chip wavelength division multiplexing function can be achieved, which is demonstrated in experiments. The ultrafast response time of one operation can be less than 20 fs. This work harmonizes the simplicity of one-dimensional SSH model with the transmissibility of two-dimensional photonic crystals, realizing transmissible on-chip zero-dimensional topological edge states. Since transmission peaks are highly sensitive to defect cavity size, this configuration can also serve as a wavelength sensor and a reconfigurable optical device, which is of substantial practical value to on-chip applications of topological photonics.

CMOS image sensor (CIS) plays a crucial role in diverse optical applications by facilitating the capture of images in the visible and near-infrared spectra. The enhancement of image resolution in CIS by an increase in pixel density is becoming more significant and realizable with the recent progress of nanofabrication. However, as pixel size decreases towards the diffraction limit, there is an inevitable trade-off between the scale-down of pixel size and the enhancement of optical sensitivity. Recently, to overcome this, an entirely new concept of spectral sensing using a nanophotonic-based color router has been proposed. In this work, we present a metasurface-based spectral router to effectively split the spectrum from visible to near-infrared and redirect through the four optical channels to the targeted pixel surfaces. We optimize the metasurface that simultaneously controls the phases of the transmitted light of targeted spectra, i.e. red (R), green (G), blue (B), and near-infrared (NIR), which is the largest number of channels reported based on a single layered metasurface and has an optical efficiency that surpasses the efficiency of conventional color filter systems.

Optical spectroscopy is a powerful tool for characterizing the properties of two-dimensional (2D) heterostructures. However, extracting the permittivity information of each 2D layer in optically thick heterostructures is challenging because of interference. To accurately measure the optical permittivity of each 2D layer in a heterostructure or on a substrate with a thick insulating spacer, such as oxides, we propose deterministic reflection contrast ellipsometry (DRCE). Our DRCE method has two advantages over conventional techniques. It deterministically measures the optical permittivity of 2D materials using only the measured reflection spectra of the heterostructure, rather than dispersion fitting as in spectroscopic ellipsometry. Additionally, the DRCE is free of excitonic energy errors in reflection-contrast spectroscopy. We believe that DRCE will enable accurate and rapid characterization of 2D materials.

Metasurface holograms offer various advantages, including wide viewing angle, small volume, and high resolution. However, full-color animation of high-resolution images has been a challenging issue. In this study, a full-color dielectric metasurface holographic movie with a resolution of 2322 × 2322 was achieved by spatiotemporally multiplexing 30 frames with blue, green, and red color channels at the wavelengths of 445 nm, 532 nm, and 633 nm at the maximum reconstruction speed of 55.9 frames per second. The high average transmittance and diffraction efficiency of 92.0 % and 72.7 %, respectively, in the visible range, were achieved by adopting polarization-independent silicon nitride waveguide meta-atoms, resulting in high color reproducibility. The superposition of three wavelengths was achieved by adjusting the resolutions and positions of target images for each wavelength while maintaining the meta-atom pitch constant. The improvement in diffraction efficiency was brought about by the optimization of etching conditions to form high-aspect vertical nanopillar structures.

Light-emitting diodes (LEDs) are widely used as next-generation light sources because of their various advantages. However, their luminous efficiency is remarkably low at the green-emission wavelength. The luminous efficiencies of InGaN/GaN quantum wells (QWs) significantly decrease with increasing indium content in the green wavelength region, mainly owing to the quantum-confined Stark effect (QCSE). This green gap problem can be solved using QWs grown on semi-polar GaN substrates, such as the {11–22} planes, to reduce the QCSE. We propose that the use of surface plasmons (SPs) is a promising way to improve the light emission efficiency of light-emitting materials such as InGaN/GaN QWs. SP resonance increases the spontaneous emission rates of the excited states, causes a relative reduction in non-radiative relaxation, and ultimately increases the internal quantum efficiencies. In this study, the light emissions of InGaN/GaN QWs grown on polar and semi-polar GaN were investigated using micro-photoluminescence (PL). We successfully enhanced the light emission of semi-polar GaN via SP resonance. The PL peak intensities and wavelengths were mapped and compared to determine the underlying mechanisms. We also measured the emission lifetimes by time-resolved PL and interpreted the detailed mechanism of SP-enhanced emissions. It was found that SP resonances can control not only the emission efficiency but also the exciton dynamics, such as exciton localization effects, QCSE screening, and defect level saturation. We conclude that the green gap problem can be solved by SP-enhanced light emission in semipolar InGaN/GaN.

Diffractive deep neural networks ( D 2 NNs ) have brought significant changes in many fields, motivating the development of diverse optical computing components. However, a crucial downside in the optical computing components is employing diffractive optical elements (DOEs) which were fabricated using commercial 3D printers. DOEs simultaneously suffer from the challenges posed by high-order diffraction and low spatial utilization since the size of individual neuron is comparable to the wavelength scale. Here, we present a design of D 2 NNs based on all-dielectric metasurfaces which substantially reduces the individual neuron size of net to scale significantly smaller than the wavelength. Metasurface-based optical computational elements can offer higher spatial neuron density while completely eliminate high-order diffraction. We numerically simulated an optical half-adder and experimentally verified it in the terahertz frequency. The optical half-adder employed a compact network with only two diffraction layers. Each layer has a size of 2 × 2 cm 2 but integrated staggering 40,000 neurons. The metasurface-based D 2 NNs can further facilitate miniaturization and integration of all optical computing devices and will find applications in numerous fields such as terahertz 6G communication, photonics integrated circuits, and intelligent sensors.

Efficient energy transfer is crucial in electromagnetic communication. Therefore, producing a waveguide coupler that achieves broadband, nonreflective transmission is a challenging task. With the advancement of silicon-based integrated photonic circuits, fiber-to-chip coupling has become increasingly important. Although various couplers have been developed for fiber-to-chip coupling, they often have limitations such as long coupling length, low coupling efficiency, and narrow bandwidth. This is due to the inability to eliminate reflections between the two waveguides. Here, we introduce a method using universal impedance matching theory and transformation optics to eliminate reflections between two waveguides. The coupler, called the universal impedance matching coupler, using this method has the shortest subwavelength coupling length, a 99.9 % coupling efficiency, and a broad bandwidth.

Proximity-field nanopatterning (PnP) have been used recently as a rapid, cost-effective, and large-scale fabrication method utilizing volumetric interference patterns generated by conformal phase masks. Despite the effectiveness of PnP processes, their design diversity has not been thoroughly explored. Here, we demonstrate that the possibility of generating any two-dimensional lattice with diverse motifs. By controlling the amplitude, phase, and polarization of each diffraction beam, we can implement all two-dimensional Bravais lattices in three-dimensional space. The results may provide diverse applications that require three-dimensional nanostructures from optical materials and structural materials to energy storage or conversion materials.

Guided exciton–polariton modes naturally exist in bare transition metal dichalcogenide (TMDC) layers due to self-hybridization between excitons and photons. However, these guided polariton modes exhibit a limited propagation distance owing to the substantial exciton absorption within the material. Here, we investigated the impact of hexagonal boron nitride (hBN) layers on guided exciton–polariton modes in WS 2 multilayers. By integrating hBN layers, we demonstrate a notable enhancement in the quality of guided exciton–polariton modes. The hBN layers can reduce substrate surface roughness and provide surface protection for the WS 2 layer, mitigating inhomogeneous broadening of the exciton resonance. Consequently, we experimentally observed that the propagation distance of polariton modes substantially increased with hBN layers. Additionally, the polariton spectrum broadened due to efficient exciton relaxation to the polariton states at lower energies. Comparison with simulation data emphasizes that the observed improvements are primarily attributed to enhanced exciton quality. The promising outcomes with hBN encapsulation suggest its potential to overcome strong excitonic losses of the guided exciton polariton in implementing nanophotonic devices. Furthermore, this approach provides a new avenue for exploring the novel physics of guided exciton–polariton modes and their potential applications in polariton-based all-optical integrated circuits.

Finding an optimal device structure in the vast combinatorial design space of freeform nanophotonic design has been an enormous challenge. In this study, we propose physics-informed reinforcement learning (PIRL) that combines the adjoint-based method with reinforcement learning to improve the sample efficiency by an order of magnitude compared to conventional reinforcement learning and overcome the issue of local minima. To illustrate these advantages of PIRL over other conventional optimization algorithms, we design a family of one-dimensional metasurface beam deflectors using PIRL, exceeding most reported records. We also explore the transfer learning capability of PIRL that further improves sample efficiency and demonstrate how the minimum feature size of the design can be enforced in PIRL through reward engineering. With its high sample efficiency, robustness, and ability to seamlessly incorporate practical device design constraints, our method offers a promising approach to highly combinatorial freeform device optimization in various physical domains.

Understanding the ultrafast excitation, detection, transportation, and manipulation of nanoscale spin dynamics in the terahertz (THz) frequency range is critical to developing spintronic THz optoelectronic nanodevices. However, the diffraction limitation of the sub-millimeter waves – THz wavelengths – has impaired experimental investigation of spintronic THz nano-emission. Here, we present an approach to studying laser THz emission nanoscopy from W|CoFeB|Pt metasurfaces with ∼60-nm lateral spatial resolution. When comparing with statistic near-field THz time-domain spectroscopy with and without the heterostructures on fused silica substrates, we find that polarization- and phase-sensitive THz emission nanoscopy is more sensitive than the statistic THz scattering intensity nanoscopy. Our approach opens explorations of nanoscale ultrafast THz spintronic dynamics in optically excited metasurfaces.

The linear electro-optic effect offers a valuable means to control light properties via an external electric field. Lithium niobate (LN), with its high electro-optic coefficients and broad optical transparency ranges, stands out as a prominent material for efficient electro-optic modulators. The recent advent of lithium niobate-on-insulator (LNOI) wafers has sparked renewed interest in LN for compact photonic devices. In this study, we present an electro-optic modulator utilizing a thin LN film sandwiched between top and bottom gold (Au) film electrodes, forming a Fabry–Pérot (F–P) resonator. This resonator exhibits spectral resonance shifts under an applied electric field, enabling efficient modulation of reflected light strength. The modulator achieved a 2.3 % modulation amplitude under ±10 V alternating voltage. Our approach not only presents a simpler fabrication process but also offers larger modulation amplitudes compared to previously reported metasurface based LN electro-optic modulators. Our results open up new opportunities for compact electro-optic modulators with applications in beam steering devices, dynamic holograms, and spatial light modulators, and more.

With rapid development of holography, metasurface-based holographic communication scheme shows great potential in development of adaptive electromagnetic function. However, conventional passive metasurfaces are severely limited by poor reconfigurability, which makes it difficult to achieve wavefront manipulations in real time. Here, we propose a holographic communication strategy that on-demand target information is firstly acquired and encoded via a depth camera integrated with modified YOLOv5s target detection algorithm, then transmitted by software defined radio modules with long term evolution at 5 GHz, and finally reproduced in the form of holographic images by spin-decoupled programmable coding metasurfaces at 12 GHz after decoding through modified Gerchberg–Saxton algorithm. Experiments are conducted to demonstrate the brand-new concept of optical information conversion to electromagnetic one via above intelligent scheme. Our strategy may open a novel avenue toward applications of near-field communication based on adaptive variation of electric field patterns (i.e. holographic images).
