As the demand for smaller and more compact lasers increases, the physical dimensions of laser diodes are already at the diffraction limit, which impairs this miniaturization trend and limits direct laser integration into photonic and especially nanophotonic circuits. However, plasmonics has allowed the development of a novel class of lasers that can be manufactured without being limited by diffraction, exhibiting ultralow energy consumption, small volumes, and high modulation speeds that could someday compete with their modern macroscale counterparts. Nevertheless, a wide variety of issues create roadblocks for further development and commercial adoption. Here we conduct a monolithic review in which we formulate the definition of a nanolaser, categorize nanolasers, and examine their properties and applications to determine if nanolasers do present a potential technological revolution as they seem to exhibit or are too restricted by the issues that plague them to ever succeed.

Nonlocal and quantum mechanical phenomena in noble metal nanostructures become increasingly crucial when the relevant length scales in hybrid nanostructures reach the few-nanometer regime. In practice, such mesoscopic effects at metal–dielectric interfaces can be described using exemplary surface-response functions (SRFs) embodied by the Feibelman d -parameters. Here we show that SRFs dramatically influence quantum electrodynamic phenomena – such as the Purcell enhancement and Lamb shift – for quantum light emitters close to a diverse range of noble metal nanostructures interfacing different homogeneous media. Dielectric environments with higher permittivities are shown to increase the magnitude of SRFs calculated within the specular-reflection model. In parallel, the role of SRFs is enhanced in noble metal nanostructures characterized by large surface-to-volume ratios, such as thin planar metallic films or shells of core–shell nanoparticles, for which the spill-in of electron wave functions enhances plasmon hybridization. By investigating emitter quantum dynamics close to such plasmonic architectures, we show that decreasing the width of the metal region, or increasing the permittivity of the interfacing dielectric, leads to a significant change in the Purcell enhancement, Lamb shift, and visible far-field spontaneous emission spectrum, as an immediate consequence of SRFs. We anticipate that fitting the theoretically modelled spectra to experiments could allow for experimental determination of the d -parameters.

Manipulating the propagation of mid-infrared (mid-IR) light is crucial for optical imaging, biosensing, photocatalysis, and guiding photonic circuits. Artificially engineered metamaterials were introduced to comprehensively control optical waves. However, fabrication challenges and optical losses have impeded the progress. Fortunately, two-dimensional van der Waals (vdW) materials are alternatives because of their inherent optical properties, such as hyperbolic behavior, high confinement, low loss, and atomic-scale thickness. In this research, we conducted theoretical and numerical investigations on the α -phase molybdenum trioxide, a biaxial vdW material, with patterned graphene to assess the potential of the tunable focusing of mid-IR light. Our proposed method directly alters the path of excited light to focus mid-IR light by negative refraction. Further, the patterned graphene in our design offers enhanced focusing characteristics, featuring a significantly reduced waist diameter with 1/92 of the free-space wavelength, an enhanced beam quality without pronounced field ripples, and a fivefold increase in field intensity. Moreover, our approach significantly preserves the waist diameter of the focused beam while facilitating directional steering. Thus, the focused beam can propagate in a canalized manner toward the desired direction. These advancements lay the foundation for promising applications in planar photonics.

Converting transverse photons into longitudinal two-dimensional plasmon-–polaritons (2D-PP) and vice versa presents a significant challenge within the fields of photonics and plasmonics. Therefore, understanding the mechanism which increases the photon – 2D-PP conversion efficiency could significantly contribute to those efforts. In this study, we theoretically examine how efficiently incident radiation, when scattered by a silver spherical nanoparticle (Ag-NP), can be transformed into 2D-PP within van der Waals (vdW) heterostructures composed of hexagonal boron nitride and graphene (hBN/Gr composites). We show that the Dirac plasmon (DP) excitation efficiency depends on the Ag-NP radius as R 3 , and decreases exponentially with Ag-NP height h , so that for a certain Ag-NP geometry up to 25 % of the incident electrical field is channeled into the DP. We demonstrate that the linear plasmons (LPs) excitation efficiency can be manipulated by changing the graphene–graphene distance Δ (or hBN thickness) or by changing the number of graphene layers N . By increasing Δ and/or N the LPs move towards smaller wave vectors Q and become accessible by the Ag-NP dipole field, so that for N ≥ 5 the excitation of more than one LP is possible. These results are supported by recent scattering-type scanning near-field optical microscopy (s-SNOM) measurements. Furthermore, we show that Ag-NPs with specific parameters preferentially hybridizes with DPs of a particular wavelength λ D , facilitating selective excitation of DPs. The obtained tuning possibilities could have a significant impact on applied plasmonics, photonics or optoelectronics.

Trapping and manipulating micro-objects and achieving high-precision measurements of tiny forces and displacements are of paramount importance in both physical and biological research. While conventional optical tweezers rely on tightly focused beams generated by bulky microscope systems, the emergence of flat lenses, particularly metalenses, has revolutionized miniature optical tweezers applications. In contrast to traditional objectives, the metalenses can be seamlessly integrated into sample chambers, facilitating flat-optics-based light manipulation. In this study, we propose an experimentally realized transmissive and polarization-insensitive water-immersion metalens, constructed using adaptive nano-antennas. This metalens boasts an ultra-high numerical aperture of 1.28 and achieves a remarkable focusing efficiency of approximately 50 % at a wavelength of 532 nm. Employing this metalens, we successfully demonstrate stable optical trapping, achieving lateral trapping stiffness exceeding 500 pN/(μm W). This stiffness magnitude aligns with that of conventional objectives and surpasses the performance of previously reported flat lenses. Furthermore, our bead steering experiment showcases a lateral manipulation range exceeding 2 μm, including a region of around 0.5 μm exhibiting minimal changes in stiffness for smoothly optical manipulation. We believe that this metalens paves the way for flat-optics-based optical tweezers, simplifying and enhancing optical trapping and manipulation processes, attributing ease of use, reliability, high performance, and compatibility with prevalent optical tweezers applications, including single-molecule and single-cell experiments.

Optically levitated multiple nanoparticles have emerged as a platform for studying complex fundamental physics such as non-equilibrium phenomena, quantum entanglement, and light–matter interaction, which could be applied for sensing weak forces and torques with high sensitivity and accuracy. An optical trapping landscape of increased complexity is needed to engineer the interaction between levitated particles beyond the single harmonic trap. However, existing platforms based on spatial light modulators for studying interactions between levitated particles suffered from low efficiency, instability at focal points, the complexity of optical systems, and the scalability for sensing applications. Here, we experimentally demonstrated that a metasurface which forms two diffraction-limited focal points with a high numerical aperture (∼0.9) and high efficiency (31 %) can generate tunable optical potential wells without any intensity fluctuations. A bistable potential and double potential wells were observed in the experiment by varying the focal points’ distance, and two nanoparticles were levitated in double potential wells for hours, which could be used for investigating the levitated particles’ nonlinear dynamics, thermal dynamics and optical binding. This would pave the way for scaling the number of levitated optomechanical devices or realizing paralleled levitated sensors.

The investigation of optical phenomena in the strong-field regime requires few-cycle laser pulses at field strengths exceeding gigavolts per meter (GV/m). Surprisingly, such conditions can be reached by tightly focusing pJ-level pulses with nearly octave spanning optical bandwidth onto plasmonic nanostructures, exploiting the field-enhancement effect. In this situation, the Gouy phase of the focused beam can deviate significantly from the monochromatic scenario. Here, we study the effect of the Gouy phase of a pulse exploited to drive coherent strong-field photocurrents within a plasmonic gap nanoantenna. While the influence of the specific Gouy phase profile in the experiment approaches the monochromatic case closely, this scheme may be utilized to identify more intricate phase profiles at sub-diffraction scale. Our results pave the way for Gouy phase engineering at picojoule (pJ) pulse energy levels, enabling the optimization of strong-field optical phenomena.

The emerging field of photonic topological insulators offers promising platforms for high-performance optical communication, computing, and sensing. However, conventional photonic topological insulator designs typically operate within the diffraction limit due to their dielectric nature. This limitation imposes constraints on device miniaturization, reduces light–matter interaction, and decreases overall device sensitivity. Introducing a new valley-Hall hybrid plasmonic topological insulator, we overcome this limitation by exploiting the coupling of surface plasmon oscillations with the optical modes of a dielectric photonic crystal, allowing for sub-diffraction vertical confinement of light. Deep-subwavelength chiral edge states can, therefore, be generated and robustly guided along disordered Z-shaped topological boundaries with much lower propagation loss compared to purely plasmonic platforms. Such extreme manipulation of light on an integrated chip platform maximizes light–matter interaction and opens the door for truly compact and efficient optical modulators, molecular sensors, and next-generation nanophotonic and quantum devices.

Whispering gallery mode (WGM) resonators, as an integral component of integrated photonics, have attracted considerable attention due to their high Q factor, small footprint, and small mode volume, making them widely applied as microlasers. In this work, Nd:GGG crystal was prepared into a Nd:GGG film with thickness of 1.8 μm through ion implantation-enhanced etching (IIEE) technique, and subsequently, the Nd:GGG film was partened by focused ion beam (FIB) technology to generate a microdisk with diameter of 20 μm. For high-power microcavity lasers, heat generation during laser operation was inevitable. We placed the microdisk on a silica holder and a silica wafer, respectively. The microdisk placed on the silica holder and silica wafer exhibited laser thresholds of 32 μW and 17 μW, respectively. Moreover, due to different heat dissipation conditions, the microdisk placed on the silica holder exhibited a mode shift of 0.13 nm/mW, while the microdisk placed on the silica wafer showed a more stable laser output state with a mode shift of 0.02626 nm/mW.

Silicon photonic waveguide resonators, such as microring resonators, photonic crystal waveguide cavities, and Fabry–Perot resonators based on the distributed Bragg reflectors, are key device components for silicon-based photonic integrated circuits (Si-PIC). For the Si-PIC with high integration density, the device footprints of the conventional photonic waveguide resonators need to be more compact. Inverse design, which is operated by the design expectation and different from the conventional design methods, has been investigated for reducing the photonic device components nowadays. In this paper, we inversely designed the silicon photonic waveguide reflectors for two target wavelengths: one is 1310 nm and the other is 1550 nm. The silicon photonic waveguide reflectors have reflectance of 0.99993 and 0.9955 for the wavelength of 1310 nm and 1550 nm each with 5-μm-long reflectors. Also, we theoretically investigated Fabry–Perot resonators based on the inversely designed photonic waveguide reflectors. Q factors of the Fabry–Perot resonators have been calculated to be 1.3 × 10 5 for the wavelength of 1310 nm and 2583 for the wavelength of 1550 nm. We have expected that the inversely designed photonic waveguide reflectors and their applications for the Fabry–Perot resonators can be utilized for compact passive/active device components such as wavelength filters, modulators, and external cavity lasers.

Photonic-integrated circuits based on erbium-doped thin film lithium niobate on insulator has attracted broad interests with insofar various waveguide amplifiers and microlasers demonstrated. Wideband operation facilitated by the broadband absorption and emission of erbium ions necessitates the functional integration of wavelength filter and multiplexer on the same chip. Here, a low-loss wavelength division multiplexer at the resonant pumping and emission wavelengths (∼1480 nm and 1530–1560 nm) of erbium ions based on angled multimode interferometer is realized in the erbium-doped thin film lithium niobate on insulator fabricated by the photolithography assisted chemomechanical etching technique. The minimum on-chip insertion losses of the fabricated device are <0.7 dB for both wavelength ranges, and a 3-dB bandwidth of >20 nm is measured at the telecom C-band. Besides, direct visualization of the multimode interference pattern by the visible upconversion fluorescence of erbium ions compares well with the simulated light propagation in the multimode interferometer. Spectral tuning of the wavelength division multiplexer by structural design is also demonstrated and discussed.

Light–matter interactions between plasmonic and excitonic modes have attracted considerable interest in recent years. A major challenge in achieving strong coupling is the identification of suitable metallic nanostructures that combine tight field confinement with sufficiently low losses. Here, we report on a room-temperature study on the interaction of tungsten disulfide (WS 2 ) monolayer excitons with a hybrid plasmon polariton (HPP) mode supported by nanogroove grating structures milled into single-crystalline silver flakes. By engineering the depth of the nanogroove grating, we can change the character of the HPP mode from propagating surface plasmon polariton-like (SPP-like) to localized surface plasmon resonance-like (LSPR-like). Using reflection spectroscopy, we demonstrate strong coupling with a Rabi splitting of 68 meV between the WS 2 monolayer excitons and the lower HPP branch for an optimized nanograting configuration with 60 nm deep nanogrooves. In contrast, only weak coupling between the constituents is observed for shallower and deeper nanogratings since either the field confinement provided by the HPP is not sufficient or the damping is too large. The possibility to balance the field confinement and losses render nanogroove grating structures an attractive platform for future applications.

The article entitled “Fast and accurate electromagnetic field calculation for substrate-supported metasurfaces using the discrete dipole approximation (DDA)” written by W. Liu and E. McLeod presents a method for computing the Green function in presence of a substrate or multilayer in an efficient way. Unfortunately, the proposed method has been known for more than twenty years and significantly ameliorated. It can be found in its optimized version in some open-source DDA codes. In this comment, we recall the different approaches (and related papers) addressing the computation of the Green function of a multilayered system. We show that they address all the points raised by Liu and McLeod in their paper and provide more efficient solutions to their computational issues.

The recent comment on our previously published article questioned the novelty and computational efficiency of our work. Here we respond by restating the novelty and scientific value of our work as well as showing why the specific alternative methods stated in the comment are unlikely to outperform the methods we compare for metasurface applications involving high refractive index particles near high refractive index substrates.
