Study on the preparation and characterization of high-dispersibility nanosilica

2.1 Experimental materials

The relevant parameters of nanosilica and the silane coupling agent KH570 in the experiments are shown in Tables 1 and 2. Other additional experimental materials included absolute ethyl alcohol, acetic acid, sodium hydroxide, and hydrochloric acid. All the above experimental materials were available in the market, and they were all in accordance with green environmental protection requirements.

2.2 Experimental methods

The experiments were carried out according to the following steps. First, the common nanosilica powder was dried at 120°C for 4 h in a drying oven; second, an ethanol/water solution (volume ratio 11:1, total volume not more than two-thirds of the capacity of the flask) was blended in a three-necked flask with a reflux condenser and magnetic stirring; third, appropriate amounts of the dried nanosilica powder and the silane coupling agent KH570 (mass fraction ratio, 3% of nanosilica powder) were added into the ethanol/water solution, and the pH of the mixture was adjusted to about 4–5 by adding acetic acid solution; fourth, the three-necked flask was placed in a water bath, and the modification reaction of the above mixing solution sustained for 2 h at a temperature of 80°C with magnetic stirring; fifth, separation of the above mixing solution was conducted on a centrifuge (10,000 rpm) for 3 min, and the precipitate at the bottom of the flask was obtained after the supernatant was poured out; sixth, the precipitate was dried at 120°C for 48 h in a drying oven after it was washed with acetone several times, finally yielding the high-dispersibility nanosilica powder.

The three key experimental parameters of step four above were optimized and chosen with the orthogonal test method, and the experimental factors and levels are shown in Table 3.

The activation grade and the surface hydroxyl number were tested for each high-dispersibility nanosilica powder obtained from each set of the test conditions. A high activation degree means excellent dispersibility, whereas a low surface hydroxyl number means a strong bonding affinity between it and the organic phases. Repeated confirmatory tests for each of the above tests were carried out, and the activation grade and the surface hydroxyl number values were averaged. These values comprehensively characterized the modification effect of the nanosilica powder.

The dispersibility effect of the high-dispersibility nanosilica powder prepared with the test conditions optimized and chosen with the orthogonal test method was characterized by infrared spectroscopy (IR), X-ray diffraction (XRD), and scanning electron microscope (SEM) analyses from different views. IR analysis was conducted with a TENSOR27 Fourier transformation infrared spectrometer (measurement range: 400–4000 cm^-1; Bruker Corporation, Germany), with the tablet specimen being diluted with KBr. The crystal structure of the dispersed nanosilica powder was analyzed by XRD analysis using the D8 Advance X-ray diffractometer produced by Bruker Corporation, with CuKα being the radiation source, the tube current being 20 mA, and tube voltage being 30 kV. SEM observation was conducted using an S-3000N scanner produced by Hitachi Japan.

The activation grade, expressed as η, is the ratio of the weight of the floating part in water and the total weight of the sample. The test methods were as the follows: first, 50 ml deionized water was placed into a 100 ml separatory funnel, and m₁ grams of dispersed nanosilica powder was added into the separatory funnel; second, the mixture was vibrated for 5 min and then allowed to stand for 30 min; third, the powder sinking in water was placed into a fixed weight crucible; fourth, the powder sinking in water was dried in a drying oven, and then the weight of the powder sinking in water was measured (m₂ grams); finally, the activation grade was derived according to Formula (3)

The surface hydroxyl number, expressed as N, was determined and calculated as follows: first, 25 ml of absolute ethyl alcohol and 75 ml of 20% NaCl solution were placed in a 200 ml beaker, and m grams of dispersed nanosilica powder was added into the beaker; second, vibration through magnetic stirring was conducted and the pH of the mixture was adjusted to 4 by adding 0.1 mol/l HCl solution; third, the pH of the mixture was adjusted to 9 by adding 0.1 mol/l NaOH solution, and the volume of NaOH solution needed was recorded as V milliliters; finally, the surface hydroxyl number was derived according to Formula (4)

where C=concentration of NaOH solution, 0.1 mol/l; V=volume of NaOH solution need, ml; N_A=Avogadro’s number; S=specific surface area of nanosilica, nm² g^-1; m=weight of nanosilica, g.

3.1 Results of the orthogonal test design and the corresponding analyses

The scheme of the orthogonal test design and the corresponding test results of the activation grade and the surface hydroxyl number are shown in Table 4.

On the basis of the calculation of the sum of the experimental results (T), the average value (t), and the range (R), the superior levels, and the primary- and secondary-influence experimental factors were measured, as shown in Table 5. The optimized combination of experimental parameters for the activation grade was A2B2C2, whereas that for the surface hydroxyl number was B2A2C2.

Thus, the superior levels for the activation grade and the surface hydroxyl number were all level 2, which means that the optimized combination of experimental parameters was as follows: mass fraction ratio of the silane coupling agent KH570, 3%; modification reaction temperature, 80°C; and modification reaction time, 2 h. However, the optimized combination of experimental parameters above was not included in the scheme of the orthogonal test design. Therefore, repeated confirmatory parallel experiments with the above-mentioned optimized combination of experimental parameters were conducted. The results of the activation grade and the surface hydroxyl number are shown in Table 6. The IR, XRD, and SEM patterns are shown in the Figures 1–3.

Figure 1

Infrared spectroscopy of nanosilica.

(A) Unmodified. (B) Modified with KH570.

Figure 2

SEM of nanosilica.

(A) Unmodified. (B) Modified with KH570.

Figure 3

XRD pattern of nanosilica.

(A) Unmodified. (B) Modified with KH570.

The optimized combination of experimental parameters meant that all factors were in the middle level. Only a single molecular coating layer around the nanosilica powder was needed; >3% silane coupling agent KH570 would result in the deterioration of the modification effect because of the self-aggregation of the silane coupling agent KH570. However, <3% of KH570 could not eliminate the self-aggregation of the nanosilica powder because only a small quantity of the surface of the nanosilica powder was covered by KH570. Not enough energy could be afforded to the modification reaction at a low modification temperature. With the increase of modification temperature, the intermolecular thermal motion became intense, the probability of intermolecular collision increased, the percentage of grafting between KH570 and the nanosilica powder increased, and the modification effect became superior [8]. In contrast, the self-aggregation, decomposition of KH570, or even the reverse reaction between KH570 and the nanosilica powder would be inevitable because of the intense intermolecular thermal motion in the higher modification temperature of >80°C; therefore, the modification effect would become negative. To consider the reaction time, it was found that regardless of the activation grade or the surface hydroxyl number, the results from different levels of experiments showed a narrow difference according to their ranges, R. Thus, it was concluded that the reaction time had a limited impact on the modification reaction [9].

3.2 IR analysis of the nanosilica

The IR spectrum of unmodified and modified nanosilica is shown in Figure 1A and B, respectively. Normal absorption peaks existed in the IR spectrum of the unmodified nanosilica, including the stretching vibration absorption peak of Si-O at 808 and 1106 cm^-1, bending vibration absorption peak of O-H at 1640 cm^-1, stretching vibration absorption peak of Si-O-H and stretching vibration absorption peak of O-H at 3412 cm^-1, as Figure 1A shows. However, there were new characteristic absorption peaks existing in the IR spectrum of nanosilica modified by the silane coupling agent KH570. There were vibration absorption peaks of C-C at 1505 cm^-1 and of -CH₃ and -CH₂ at 2928 cm^-1, which fully proved the presence of organic bond groups in the nanosilica modified by KH570, as Figure 1B shows. At the same time, owing to the obvious increase of peak intensity and peak area at 3460 cm^-1, the increase of Si-O-H bonds in the modified nanosilica by KH570 was the evidence that Formula (1) was completed. Furthermore, owing to the much stronger stretching vibration absorption peak of Si-O at 808 and 1106 cm^-1, the increase of Si-O bonds in the nanosilica modified by KH570 proved that Formula (2) was completed. From the chemistry viewpoint, the modification was successful and the high dispersibility and hydrophobicity of the modified nanosilica was assured [10].

3.3 SEM analysis

Of course, the most apparent and intuitive evidence of the excellent dispersion effect was taken from the SEM observation. The different SEM morphologies of the particle distribution between the unmodified and the modified nanosilica are shown in Figure 2A and B.

3.4 XRD analysis of the nanosilica

Moreover, no apparent changes occurred in the XRD patterns of the modified nanosilica powder, proving that the crystal structure of nanosilica powder remained amorphous after the modification by the silane coupling agent KH570, as shown in Figure 3A and B.
