Two-Dimensional Modeling of an Externally Irradiated Slurry Photoreactor

  • Giovanni Palmisano EMAIL logo , Vittorio Loddo und Vincenzo Augugliaro
Veröffentlicht/Copyright: 25. Juni 2013
Veröffentlichen auch Sie bei De Gruyter Brill
Manuskript einreichen Informationen für Autor*innen
International Journal of Chemical Reactor Engineering
Aus der Zeitschrift International Journal of Chemical Reactor Engineering Band 11 Heft 2

Abstract

A batch cylindrical photocatalytic reactor, externally irradiated by 1–6 UV fluorescent lamps and containing a stirred slurry of polycrystalline TiO2, was modeled by coupling a modified Langmuir–Hinshelwood kinetics together with a two-dimensional light intensity field. The radiation field has been determined on the main assumptions of diffuse radiation, isotropic scattering and negligible backward reflected photon flow. The model has been applied to the photocatalytic oxidation of organic substrates which do not undergo homogeneous photochemical degradation. The model is characterized by the following four parameters: the kinetic constants of substrate adsorption, desorption and degradation and the exponent of the power law expressing the kinetics dependence on the light intensity. The model constants may be determined by applying a simple least-squares best fitting procedure.

Keywords: photoreactor modeling; externally irradiated photoreactor; Langmuir–Hinshelwood kinetics

Appendix A: Geometrical derivation of r1and r2as a function of θ, r0and R

The coordinate system used was indicated by (x, y) in Figure 6.

Figure 6 Geometric scheme referred to reactor and lamp (grey).
Figure 6

Geometric scheme referred to reactor and lamp (grey).

[28]
[28]
[29]
[29]

Substituting eq. [29] in eq. [28]:

[30]
[30]

Developing the square present in eq. [30] and substituting ith :

[31]
[31]

Substituting with in eq. [31]:

[32]
[32]

By solving eq. [32] with respect to :

[33]
[33]

By considering the following equation coming from Pythagorean theorem applied to the down-right triangle and by applying eq. [29]:

[34]
[34]

By substituting eq. [33] in eq. [34]:

[35]
[35]

Finally:

[36]
[36]

whereas by applying the plus sign in eq. [33] one gets the relationship for r2:

[37]
[37]

Appendix B: Geometrical derivation of rII, rIII, rIV, rV, rVI, θ2, θ3, θ4, θ5 and θ6

Figure 7 Geometric scheme referred to lamp 1 reference system.
Figure 7

Geometric scheme referred to lamp 1 reference system.

[38]
[38]
[39]
[39]
[40]
[40]
[41]
[41]
[42]
[42]
[43]
[43]

Notations

A [m2]catalyst surface area (specific surface area multiplied by weight)
b [dimensionless]parameter defined by eq. [8]
Ccat [g m–3]catalyst concentration
Ci [mmol m–3]concentration of I-intermediate
CSub [mmol m–3]substrate concentration
CSub,0 [mmol m–3]substrate initial concentration
e [dimensionless]Napierian extinction coefficient
I [W m–2]light radiation flux coming from one lamp in the positive propagation direction
I0 [W m–2]light radiation flux coming from one lamp at boundary medium (between light source and reacting suspension)
I0,r1 [W m–2]light radiation flux coming from one lamp at boundary medium as a function of r1
Iλ [W m–2]local radiation intensity
J [W m–2]radiation flux in the opposite propagation direction
k [m–1]absorption coefficient
k* [m2 g–1]absorption coefficient per unit concentration
k′ [mmol m–2 h–1]absolute kinetic constant (not depending on light intensity)
k1″ [mmol m–2 h–1] = k′′θOxL.-H. surface pseudo-first-order kinetic rate constant
k2″ [mmol m–2 h–1]L.-H. second-order kinetic rate constant
kads [m3mmol–1]substrate adsorption kinetic constant
kdes [m3mmol–1]substrate desorption kinetic constant
KSub [m3mmol–1]reagent equilibrium adsorption constant
Ki [m3mmol–1]intermediate products equilibrium adsorption constant
kobs [m h–1]observed pseudo-first-order disappearance rate
l [m]light path length; coordinate along which propagation occurs
NSub [mmol]phenol moles present in the liquid phase
r [m]distance between light source and a reactant element, i.e. cylindrical radial coordinate
r0 [m]smaller distance between light source and external reactor wall
r1 [m] = (r–l)distance between light source 1 and circumference points nearer to the light source (see Figures 2 and 6)
r2 [m]distance between light source 1 and circumference points farer from the light source (see Figures 2 and 7)
rII, rIII, rIV, rV, rVI [m]distance between light source II, III, IV, V, VI and circumference points nearer to the light source (see Appendix B)
rSub [mmol m–2 h–1]volumetric averaged surface reaction rate
R [m]reactor radius
R∞ [dimensionless]diffuse reflectance
s [m–1]scattering coefficient
s* [m2 g–1]scattering coefficient per unit concentration
S [m2]cross-sectional area of the photoreactor
t [h]reaction time
V [m3]reaction volume
α [dimensionless]parameter varying from 0.5 to 1 (present as an exponent in eq. [18])
θ [rad]cylindrical angular coordinate referred to lamp 1
θ2, θ3, θ4, θ5, θ6[rad]cylindrical angular coordinate referred to lamp 2, 3, 4, 5, 6
θ* [dimensionless]fractional site coverage
θ0 [rad]boundary cylindrical angular to be considered
θOx [dimensionless]oxygen fractional site coverage
θSub [dimensionless]reagent fractional site coverage
λ [m]radiation wavelength

References

1 Cabrera MI, Alfano OM, Cassano AE. Novel reactor for photocatalytic kinetic studies. Ind Eng Chem Res 1994;33:3031–42.10.1021/ie00036a019Suche in Google Scholar

2 Li Puma G, Brucato A. Dimensionless analysis of slurry photocatalytic reactors using two-flux and six-flux radiation absorption-scattering models. Catal Today 2007;122:78–90.10.1016/j.cattod.2007.01.027Suche in Google Scholar

3 Colina-Márquez J, Machuca-Martínez F, Li Puma G. Photocatalytic mineralization of commercial herbicides in a pilot-scale solar CPC reactor: photoreactor modeling and reaction kinetics constants independent of radiation field. Environ Sci Technol 2009;43:8953–60.10.1021/es902004bSuche in Google Scholar

4 Camera-Roda G, Santarelli F. A rational approach to the design of photocatalytic reactors. Ind Eng Chem Res 2007;46:7637–44.10.1021/ie070302aSuche in Google Scholar

5 Ray AK. Design, modelling and experimentation of a new large-scale photocatalytic reactor for water treatment. Chem Eng Sci 1999;54:3113–25.10.1016/S0009-2509(98)00507-7Suche in Google Scholar

6 Li D, Xiong K, Li W, Yang Z, Liu C, Feng X, Lu X. Comparative study in liquid-phase heterogeneous photocatalysis: model for photoreactor scale-up. Ind Eng Chem Res 2010;49:8397–405.10.1021/ie100277gSuche in Google Scholar

7 Arancibia-Bulnes CA, Bandala ER, Estrada CA. Radiation absorption and rate constants for carbarylphotocatalytic degradation in a solar collector. Catal Today 2002;76:149–59.10.1016/S0920-5861(02)00215-8Suche in Google Scholar

8 Salaices M, Serrano B, De Lasa HI. Experimental evaluation of photon absorption in an aqueous TiO2 slurry reactor. Chem Eng J 2002;90:219–29.10.1016/S1385-8947(02)00037-2Suche in Google Scholar

9 Taranto J, Frochot D, Pichat P. Modeling and optimizing irradiance on planar, folded, and honeycomb shapes to maximize photocatalytic air purification. Catal Today 2007;122:66–77.10.1016/j.cattod.2007.01.031Suche in Google Scholar

10 Augugliaro V, Camera-Roda G, Loddo V, Palmisano G, Palmisano L, Parrino F, Puma MA. Synthesis of vanillin in water by TiO2 photocatalysis. Appl Catal B: Environ 2012;111–112:555–61.10.1016/j.apcatb.2011.11.007Suche in Google Scholar

11 Yoshihawa N, Kimura T, Kawase Y. Oxidative degradation of nonionic surfactants with TiO2photocatalyst in a bubbling column reactor. Can J Chem Eng 2003;81:719–24.10.1002/cjce.5450810351Suche in Google Scholar

12 Tokumura M, Znad HT, Kawase Y. Modeling of an external light irradiation slurry photoreactor: UV light or sunlight-photoassisted Fenton discoloration of azo-dye Orange II with natural mineral tourmaline powder. Chem Eng Sci 2006;61:6361–71.10.1016/j.ces.2006.05.038Suche in Google Scholar

13 Cassano AE, Alfano OM. Reaction engineering of suspended solid heterogeneous photocatalytic reactors. Catal Today 2000;58:167–97.10.1016/S0920-5861(00)00251-0Suche in Google Scholar

14 Brandi RJ, Citroni MA, Alfano OM, Cassano AE. Absolute quantum yields in photocatalytic slurry reactors. Chem Eng Sci 2003;58:979–85.10.1016/S0009-2509(02)00638-3Suche in Google Scholar

15 Modest MF. Radiative heat transfer. New York: McGraw-Hill, 1993.Suche in Google Scholar

16 Kortüm G. Reflectance spectroscopy: principles, methods, applications. New York: Springer, 1969.10.1007/978-3-642-88071-1Suche in Google Scholar

17 Yurdakal S, Loddo V, Augugliaro V, Berber H, Palmisano G, Palmisano L. Photodegradation of pharmaceutical drugs in aqueous TiO2 suspensions: mechanism and kinetics. Catal Today 2007;129:9–15.10.1016/j.cattod.2007.06.044Suche in Google Scholar

18 Augugliaro V, Loddo V, Palmisano L, Schiavello M. Performance of heterogeneous photocatalytic systems: influence of operational variables on photoactivity of aqueous suspension of TiO2. J Catal 1995;153:32–40.10.1006/jcat.1995.1105Suche in Google Scholar

19 Turchi C, Ollis DF. Photocatalytic degradation of organic water contaminants: mechanisms involving hydroxyl radical attack. J Catal 1990;122:178–92.10.1016/0021-9517(90)90269-PSuche in Google Scholar

20 Mills A, Wang J, Ollis DF. Dependence of the kinetics of liquid-phase photocatalysed reactions on oxygen concentration and light intensity. J Catal 2006;243:1–6.10.1016/j.jcat.2006.06.025Suche in Google Scholar

21 Fox MA, Dulay MT. Heterogeneous photocatalysis. Chem Rev 1993;93:341–57.10.1021/cr00017a016Suche in Google Scholar

22 Hoffmann MR, Martin ST, Choi W, Bahnemann DW. Environmental applications of semiconductor photocatalysis. Chem Rev 1995;95:69–96.10.1021/cr00033a004Suche in Google Scholar

23 Mills A, Le Hunte S. An overview of semiconductor photocatalysis. J Photochem Photobiol A: Chem 1997;108:1–35.10.1016/S1010-6030(97)00118-4Suche in Google Scholar

24 Ollis DF. Kinetics of liquid phase photocatalyzed reactions: an illuminating approach. J Phys Chem B 2005;109:2439–44.10.1021/jp040236fSuche in Google Scholar

25 Mills A, Wang J. The kinetics of semiconductor photocatalysis; light intensity effects. Z Phys 1999;213:49–58.10.1524/zpch.1999.213.Part_1.049Suche in Google Scholar

26 Emeline AV, Ryabchuk V, Serpone N. Factors affecting the efficiency of a photocatalyzed process in aqueous metal-oxide dispersions – prospect of distinguishing between two kinetic models. J Photochem Photobiol A: Chem 2000;133:89–97.10.1016/S1010-6030(00)00225-2Suche in Google Scholar

27 Martyanov I, Savinov E. Photocatalytic steady-state methylviologen oxidation in air-saturated TiO2 aqueous suspension: initial photonic efficiency and initial oxidation rate as a function of methylviologen concentration and light intensity. J Photochem Photobiol A: Chem 2000;134:219–26.10.1016/S1010-6030(00)00254-9Suche in Google Scholar

28 Xu Y, Langford CH. Variation of Langmuir adsorption constant determined for TiO2-photocatalyzed degradation of acetophenone under different light intensity. J Photochem Photobiol A: Chem 2000;133:67–71.10.1016/S1010-6030(00)00220-3Suche in Google Scholar

29 Emeline AV, Ryabchuk V, Serpone N. Dogmas and misconceptions in heterogeneous photocatalysis. Some enlightened reflections. J Phys Chem B 2005;109:18515–21.10.1021/jp0523367Suche in Google Scholar PubMed

30 Loddo V, Addamo M, Augugliaro V, Palmisano L, Schiavello M, Garrone E. Optical properties and quantum yield determination in photocatalytic suspensions. AIChE J 2006;52:2565–74.10.1002/aic.10883Suche in Google Scholar
