Optimal power dispatch in microgrids using mixed-integer linear programming
-
Renata Rodrigues Lautert
,
Cláudio Adriano C. Cambambi
Abstract
As greenhouse gases emissions continue to rise, society is actively seeking methods to reduce them. Microgrids (MGs), which predominantly consist of renewable energy sources, play a significant role in achieving this objective. This paper proposes an optimized methodology for power dispatch in MGs using mixed-integer linear programming (MILP). The MGs include photovoltaic systems, wind turbines, biogas (BG) generators, battery energy storage systems (BESS), electric vehicles (EV), and loads. The model features an objective function focused on cost minimization, power balance, and the necessary limits and constraints for the system’s safe operation. Real-time pricing is employed for energy transactions between the MGs and the main grid. The results demonstrate a cost-efficient operation for the proposed system comprising two MGs and the main grid. During periods of negative power balance, the demand was met by discharging the BESS, EV’s battery, or purchasing energy from the grid. The BESS was charged when energy prices were low and discharged during peak demand periods and high energy prices. The intermittent nature of renewable sources necessitates an efficient management system to ensure reliable operation. Additionally, storage systems help mitigate the variability in generation. The BG generator was another crucial component for power supply due to its flexibility. Integrating these components into the system improved reliability and ensured a secure and balanced operation.
Zusammenfassung
Da die Treibhausgasemissionen weiter ansteigen, sucht die Gesellschaft aktiv nach Methoden, um sie zu reduzieren. Microgrids (MGs), die überwiegend aus erneuerbaren Energiequellen bestehen, spielen eine wichtige Rolle bei der Erreichung dieses Ziels. In diesem Beitrag wird eine optimierte Methodik für die Energieverteilung in MGs unter Verwendung der gemischt-ganzzahligen linearen Programmierung (MILP) vorgeschlagen. Zu den MGs gehören Photovoltaikanlagen, Windturbinen, Biogasanlagen (BG), Batteriespeichersysteme (BESS), Elektrofahrzeuge (EV) und Lasten. Das Modell verfügt über eine Zielfunktion, die sich auf die Kostenminimierung, die Leistungsbilanz und die notwendigen Grenzen und Einschränkungen für den sicheren Betrieb des Systems konzentriert. Für die Energietransaktionen zwischen den MGs und dem Hauptnetz werden Echtzeitpreise verwendet. Die Ergebnisse zeigen einen kosteneffizienten Betrieb für das vorgeschlagene System, das aus zwei MGs und dem Hauptnetz besteht. In Zeiten negativer Leistungsbilanz wurde der Bedarf durch Entladung des BESS, der EV-Batterie oder durch den Kauf von Energie aus dem Netz gedeckt. Der BESS wurde geladen, wenn die Energiepreise niedrig waren und entladen, wenn der Bedarf am höchsten und die Energiepreise hoch waren. Die inkonstante Energieerzeugung der erneuerbaren Energiequellen erfordert ein effizientes Managementsystem, um einen zuverlässigen Betrieb zu gewährleisten. Darüber hinaus tragen Speichersysteme dazu bei, die Schwankungen in der Stromerzeugung abzumildern. Die Biogasanlage stellt aufgrund ihrer Flexibilität eine entscheidende Komponente in der Stromversorgung dar. Durch die Integration dieser Komponenten in das System wurde die Zuverlässigkeit verbessert und ein sicherer und ausgewogener Betrieb gewährleistet.
About the authors
Renata Rodrigues Lautert received her B.Sc. degree (2017) in Control and Automation Engineering, and the M.Sc. degree (2020) in Electrical Engineering both from the Federal University of Technology – Parana (UTFPR), Curitiba, Brazil. Currently, she is pursuing a Ph.D. degree in a cotutelle program at Federal University of Santa Maria (UFSM), Santa Maria, Brazil, and Otto-von-Guericke University (OVGU), Magdeburg, Germany. Her research interests include renewable energies, power systems, microgrids, distributed generation, and energy storage.
Cláudio Adriano Correia Cambambi received a Bachelor’s degree in Energy Engineering from UNILAB (2018) and a Master’s degree in Electrical Engineering from UNIFEI (2020), both in Brazil. He is currently pursuing a Ph.D. in Electrical Engineering at UFSM and is a certified Energy and Electrical Installations Technician (2011) from the Polytechnic Institute of Cacuaco (Angola). His areas of interest include distributed energy resources, microgrids, Virtual Power Plant (VPP), artificial intelligence, renewable energy, energy efficiency, and the mitigation of energy poverty in rural African communities.
Mauro dos Santos Ortiz received the B.Sc. degree and the M.Sc. degree in electrical engineering from the Federal University of Santa Maria (UFSM), Santa Maria, Brazil, in 2017 and 2019, respectively. Undergraduate in Teacher Education for Professional Education by UFSM in 2019. He is currently pursuing a Ph.D. degree in electrical engineering at UFSM with cotutelle at the Otto von Guericke University Magdeburg (OVGU), Magdeburg, Germany. Since 2023, he has been a Research Assistant with the Chair of Electric Power Networks and Renewable Energy, OVGU. His research interests include energy quality, integration of renewable energies and electromobility.
Martin Wolter received his diploma in electrical engineering in 2006, his Dr.-Ing degree in 2008 and his venia legendi in 2012 all from Leibniz University Hannover. From 2011 to 2015 he worked at 50Hertz Transmission GmbH in system operation concept development. Since 2015, he has been head of the chair of Electric Networks and Renewable Energy at Otto-von-Guericke University Magdeburg. His research topics are power system modelling and simulation, system security and system operation as well as power system dynamics.
Luciane Neves Canha, Doctor in Electrical Engineering (2004), Full Professor at the Federal University of Santa Maria (UFSM), PQ-1D Researcher at the National Research Council of Brazil and IEEE Senior Member. In 2021 she was included among the 21 most influential women in mobility in the world by Vulog. She has experience in Electrical Engineering, with an emphasis on power systems, energy transition, renewable energy sources, smart grids, energy storage, microgrids, electrical mobility and distributed generation.
