Effect of Catalyst Film Thickness on Growth Morphology, Surface Wettability and Drag Reduction Property of Carbon Nanotubes

Pretreatment of catalyst film

Figure 2 shows the influence of film thickness on the distribution of catalyst particles. The average particle sizes from Figure 2(a)–2(d) were about 70 nm, 90 nm, 150 nm and 200 nm, respectively. The measured particle densities from Figure 2(a)–2(d) were about 4.5×10⁸ cm⁻², 3.8×10⁸ cm⁻², 5.6×10⁷ cm⁻², and 7.9×10⁶ cm⁻², respectively. Figure 3 shows the AFM images of the morphology of catalyst particles. The AFM measurements were performed in tapping mode at ambient conditions. It reveals that the average particle size and density were consistent with what shown in Figure 2. The root-mean-square (rms) roughnesses from Figure 3(a)–3(d) were about 8.3 nm, 13.2 nm, 23.1 nm and 29.4 nm, respectively.

It can be inferred that the continuous film was transformed into fragmentized island morphology under thermal effect. The defect areas of them were etched by nitrogen containing groups and gas molecules decomposing from ammonia gas. Meanwhile, aggregation of small particles appeared until a balance was reached. The amount of particles and island regions remained stable. More particles appeared because of the influence of thermal effect and surface tension after a long time of annealing process. Ultimately catalyst particles were distributed evenly, which was favorable for the growth of CNTs.

Figure 2:

SEM images of nickel films with different thickness after pretreatment process (a) 5 nm, (b) 10 nm, (c) 15 nm, (d) 20 nm.

Figure 3:

AFM images of nickel films with different thickness after pretreatment process (a) 5 nm, (b) 10 nm, (c) 15 nm, (d) 20 nm.

Growth of CNTs

Figure 4 displays SEM images of CNTs grown on the substrates shown in Figures 2 and 3. It is obvious that the thickness of nickel film has a great influence on growth morphology of CNTs. It can be seen from Figure 4(a) that there was a certain preferred orientation in the CNTs with a shorter length. The surface was not smooth. Well-aligned CNTs were obtained in Figure 4(b). This is a typical scenario in CVD grown CNTs due to the Van der Waals interactions between the tubes. The overall length of CNTs increased rapidly. The length of the CNTs was approximately 20 μm. The orthogonal orientation of a single CNT got better. In Figure 4(c), with the further increase of particle size, CNTs were intertwined with each other during the growth process. The average length and diameter of CNTs were decreased. However, the overall orientation was still observed. The random orientation of the CNTs was shown in Figure 4(d). This was due to the increase of spacing between catalyst particles. It could reduce the Van der Waals interactions between the tubes. Therefore, CNTs were distorted during the growth process.

Figure 4:

SEM images of CNTs grown on different treated substrates with different nickel film thickness (a) 5 nm, (b) 10 nm, (c) 15 nm, (d) 20 nm.

Figure 5 shows typical TEM images of as-prepared samples. The morphologies of CNTs were composed of vertical and coiled structures. TEM images clearly reveal that as-prepared CNTs exhibited bamboo-like structure with well-separated transverse bridge compartments. Furthermore, bamboo-like structure was more obvious for larger CNTs. HRTEM image clearly indicates the defects and roughness within the wall of CNTs. The tube wall constitutes more than 30 graphite sheets with the corresponding size of 28 nm. The graphitization degree of inner tube was much better than external tube, even amorphous structures existed in several areas of external tube. The estimated interlayer distance was about 0.365 nm, which was greater than that of graphite (0.334 nm [12]).

Figure 5:

TEM images of aligned carbon nanotubes (a) vertical CNTs, (b) coiled CNTs, (c) bamboo-shaped structure, (d) HRTEM image of single CNT.

EDX was performed to determine the element composition in different areas of CNTs. As shown from Figure 6, the top of CNTs was abundant in nickel element. There was little nickel element in interior tubes and roots of CNTs. This suggested the weak binding force between the catalyst particle and the substrate, which was responsible for the tip growth mechanism of CNTs [13]. Nitrogen element was not found in Figure 6, which revealed the nitrogen-doped content of CNTs was not large. Consequently, there was little structural defect which was caused by the nitrogen-doped content from the decomposition of ammonia gas.

Figure 6:

EDX analysis of aligned CNTs (a) the top, (b) the tube body, (c) the root.

Surface wettability of CNTs

Distilled water was used as liquid probe to characterize the surface wettability of CNTs. Figure 7 shows the influence of nickel film thickness on the contact angle of droplets. The solid–liquid contact angle increased with the increase of nickel film thickness. As seen from Figure 4, a similar columnar structure was obtained when the thickness of nickel film reached 5 nm and 15 nm. The column spacing of CNTs grown on nickel film with 15 nm was more spacious than that of 5 nm. Correspondingly, the contact angle of CNTs grown on nickel film with 15 nm was larger than that of 5 nm. It followed the overall trend of the Cassie–Baxter formula [14]. According to a study by Alexander Otten et al. [15], although it was hard to determine the wettability of a single CNT, when CNT bundle with hydrophobic property was immersed into liquid drop, a bending deformation was followed to exert a repulsive force. This repulsive force would reduce the infiltration of liquid to solid surface. As the thickness of nickel film continued to increase, the bending degree of CNTs was also increased. In addition, the contact area between a single CNT and liquid drop was increased, which enhanced the repulsive force between the CNTs and liquid drop. On the other hand, catalyst particles with larger size reduced the growth density of CNTs. The air volume was markedly increased, which decreased the infiltration pressure of liquid [16]. Consequently, the surface hydrophobicity was improved.

Figure 7:

Effect of the nickel film thickness on the contact angle of water on CNTs.

Drag reduction property of CNTs

For nearly a hundred years, scientists and engineers have applied the no-slip boundary condition to fluid flow over a solid surface. While the well-accepted no-slip boundary condition has been validated experimentally for a number of macroscopic flows, it remains an assumption not based on physical principles [17]. Navier’s proposed boundary condition assumes that the velocity (vx), at a solid surface is proportional to the shear rate at the surface [18].

where b is the slip length or slip coefficient. If b is zero, the generally assumed no-slip boundary condition is obtained. If b is finite, fluid slip occurs at the wall, but its effect depends upon the length scale of the flow.

When the liquid molecules slip along the solid surface, the rheological characteristics of fluid in our experimental apparatus can be described by the following equation.

where M is torque value, R is the radius of the fixture, μ is viscidity of the liquid, D is the spacing between the fixture and the sample, ω is the rotation speed of the fixture, ϖ is effective slip velocity of the sample.

So the following formula was obtained.

The following formulas can also be deduced

where γ is defined as shear rate.

Figure 8 shows the rheological characteristics of distilled water on CNTs prepared with different thickness of nickel films. There was a linear relationship between the torque and shear rate. The two lines corresponding to 5 nm and 15 nm almost coincided with each other and passed through the origin regardless of the numerical value of D. This revealed that no slip occurred. By contrast, the two lines corresponding to 5 nm and 15 nm did not pass through the origin, which provided evidence for the existence of slip effect. Under the same shear rate, the torque value corresponding to 25 nm was larger than that corresponding to 45 nm. This suggests that the flow resistance of a fluid on the surface corresponding to 45 nm was larger than that corresponding to 25 nm. The difference was slightly reduced with the increase of D.

Figure 8:

The rheological characteristics of distilled water on CNTs prepared with different thickness of nickel films (a) D = 500 μm, (b) D = 600 μm, (c) D = 700 μm.

Water in contact with a rough surface can be in one of two states. The first state is usually called the Wenzel state. If the gas trapping is significant, the second is often called the Cassie state [19]. The wetting transition from Cassie state to Wenzel state comes with conditions. Hydraulic pressure caused by torque ripples is an important factor to cause a transition from Cassie state to Wenzel state. In our experiment, the liquid slip on hydrophobic surfaces was not obvious. Therefore, the variation of torque ratio of superhydrophobic surface to hydrophobic surface with shear rate can reflect the wetting state transition to some extent [20]. Figure 9 presents the variation of torque ratio of superhydrophobic surface to hydrophobic surface with shear rate under different values of D. It is evident that the torque ratio decreased rapidly at the initial stage and then decreased gently. The internal surface was constantly infiltrated by liquid flow with the increasing shear rate, which resulted in the wetting transition. Furthermore, the numerical value of D had no effect on the wetting transition and the transition corresponding to 45 nm was more intense than that corresponding to 25 nm. This was due to the repulsive interaction between the CNTs and fluid corresponding to 45 nm was greater than that corresponding to 25 nm. In any event, a balance between the repulsive force and the fluid infiltration would create the appearance of a final stable state.

Figure 9:

The variation of the torque ratio of CNTs prepared with different thickness of nickel films to CNTs prepared with nickel film of 5 nm thick (a) D = 500 μm, (b) D = 600 μm, (c) D = 700 μm.
