Nonlinear model reduction of dynamical power grid models using quadratization and balanced truncation

Tobias K. S. Ritschel
Tobias K. S. Ritschel received a B. Sc. degree in mathematics and technology in 2013 and a M. Sc. degree in mathematical modelling and computation in 2015 from Technical University of Denmark. In 2018, he received a Ph. D. degree in applied mathematics, also from Technical University of Denmark. Since 2020, he has been holding a position as postdoctoral researcher at the Max Planck Institute for Dynamics of Complex Technical Systems, Germany.
, Frances Weiß
Frances Weiß received a Diploma in political science from Free University Berlin and University Oslo in 2009. In 2015 and 2019, she received a B. Sc. and M.Sc in science mathematics, respectively, from Otto von Guericke University Magdeburg. Since 2020, she has been holding a position as research assistant at Fraunhofer Institute for Transportation and Infrastructure Systems, Germany.
, Manuel Baumann
Manuel Baumann received his Ph. D. in applied mathematics from Delft University of Technology in 2018. Prior to that, he studied mathematics at Technical University of Berlin (B. Sc.) and computer science at Royal Institute of Technology in Stockholm and at Delft University of Technology (M. Sc., double degree program). His research interests include numerical linear algebra, computational geophysics, and model-order reduction and optimization of power systems. He has published several journal papers in these fields including in SIAM Journal on Scientific Computing and Springer Computational Geosciences. From 2018 to 2019, he was a postdoctoral researcher at the Max Planck Institute for Dynamics of Complex Technical Systems, and since 2020, he has been holding a position as research scientist at Philips GmbH Innovative Technologies, Germany.
and Sara Grundel
Sara Grundel was born in Munich Germany in 1981. She received a Diploma in mathematics from ETH Zurich in 2005 and a Ph. D. degree in mathematics from the Courant Institute of Mathematical Sciences at New York University in New York City in 2011. Since then she has been holding a postdoctoral position at the Max Planck Institute in Magdeburg, Germany. In 2015 she became a research team leader focused on the simulation of energy system.

Published/Copyright: November 27, 2020

Published by

Become an author with De Gruyter Brill

Submit Manuscript Author Information Explore this Subject

From the journal at - Automatisierungstechnik Volume 68 Issue 12

Abstract

In this work, we present a nonlinear model reduction approach for reducing two commonly used nonlinear dynamical models of power grids: the effective network (EN) model and the synchronous motor (SM) model. Such models are essential in real-time security assessments of power grids. However, as power grids are often large-scale, it is necessary to reduce the models in order to utilize them in real-time. We reformulate the nonlinear power grid models as quadratic systems and reduce them using balanced truncation based on approximations of the reachability and observability Gramians. Finally, we present examples involving numerical simulation of reduced EN and SM models of the IEEE 57 bus and IEEE 118 bus systems.

Zusammenfassung

Dieser Artikel beschreibt einen Ansatz zur nichtlinearen Modellordnungsreduktion zweier häufig benutzter Modelle zur Beschreibung dynamischer Stromnetze, das Effektive Netzwerk (EN) Model und das Synchroner Motor (SM) Model. Solche Modelle sind essentiell in der Sicherheitsanalyse von Stromnetzen. Zur Echtzeitanalyse benötigt man für große Netze allerdings Reduktionsmethoden. Wir schreiben das nichtlineare System in ein quadratisches um, welches dann mit Hilfe von balanciertem Abschneiden, basierend auf der Steuerbarkeits- und Beobachtbarkeitsgramschen, durchgeführt wird. Im Anschluss werden numerische Simulationen der reduzierten EN und SM Modelle am IEEE 57 und IEEE 118 Bus Beispiel gezeigt.

Keywords: nonlinear model reduction; balanced truncation; dynamical power grid models; quadratic systems

Schlagwörter: nichtlineare Modellreduktion, balanciertes Abschneiden, dynamische Stromnetzmodelle, quadratische Systeme

Funding source: Bundesministerium für Bildung und Forschung

Award Identifier / Grant number: 05M18EVA

Funding statement: We acknowledge the financial support from the German Federal Ministry of Education and Research in the project KONSENS: Konsistente Optimierung und Stabilisierung Elektrischer Netzwerksysteme (BMBF grant 05M18EVA).

About the authors

Tobias K. S. Ritschel

Tobias K. S. Ritschel received a B. Sc. degree in mathematics and technology in 2013 and a M. Sc. degree in mathematical modelling and computation in 2015 from Technical University of Denmark. In 2018, he received a Ph. D. degree in applied mathematics, also from Technical University of Denmark. Since 2020, he has been holding a position as postdoctoral researcher at the Max Planck Institute for Dynamics of Complex Technical Systems, Germany.

Frances Weiß

Frances Weiß received a Diploma in political science from Free University Berlin and University Oslo in 2009. In 2015 and 2019, she received a B. Sc. and M.Sc in science mathematics, respectively, from Otto von Guericke University Magdeburg. Since 2020, she has been holding a position as research assistant at Fraunhofer Institute for Transportation and Infrastructure Systems, Germany.

Manuel Baumann

Manuel Baumann received his Ph. D. in applied mathematics from Delft University of Technology in 2018. Prior to that, he studied mathematics at Technical University of Berlin (B. Sc.) and computer science at Royal Institute of Technology in Stockholm and at Delft University of Technology (M. Sc., double degree program). His research interests include numerical linear algebra, computational geophysics, and model-order reduction and optimization of power systems. He has published several journal papers in these fields including in SIAM Journal on Scientific Computing and Springer Computational Geosciences. From 2018 to 2019, he was a postdoctoral researcher at the Max Planck Institute for Dynamics of Complex Technical Systems, and since 2020, he has been holding a position as research scientist at Philips GmbH Innovative Technologies, Germany.

Sara Grundel

Sara Grundel was born in Munich Germany in 1981. She received a Diploma in mathematics from ETH Zurich in 2005 and a Ph. D. degree in mathematics from the Courant Institute of Mathematical Sciences at New York University in New York City in 2011. Since then she has been holding a postdoctoral position at the Max Planck Institute in Magdeburg, Germany. In 2015 she became a research team leader focused on the simulation of energy system.

Appendix A Matricization

We illustrate the concept of matricization using an example given by Kolda and Bader [21]. Let H∈R3×4×2 be a tensor whose mode-1 matricization is

(32)H(1)=147101316192225811141720233691215182124.

Then, the mode-2 and mode-3 matricizations are

(33a)H(2)=123131415456161718789192021101112222324,

(33b)H(3)=123⋯101112131415⋯222324.

For more information about matricization and tensors, we refer to [21] and to previous work on model reduction of quadratic-bilinear systems [6], [7].

Appendix B Low-rank approximation

Given P=RRT where P,R∈Rn×n, we denote by R˜=Tτ(R)∈Rn×l a low-rank approximation for which R˜R˜T≈RRT=P, i. e., the purpose is to approximate P. We compute R˜ using the singular value decomposition R=UΣV:

(34)R˜=UΣl.

Here, Σl contains the first l columns of Σ, and l is chosen such that

(35)σi2>τσ12,

for i=2,…,l. The singular values σi are the diagonal entries of Σ, and they are ordered, i. e., σi≥σj for i<j.

In this work, we use the machine precision as the tolerance, i. e., τ=1.1102·10−16, in order to limit the error of the low-rank approximation.

Appendix C Efficient evaluation of the Kronecker products

We evaluate ΔKi,k in (27a) using matricization [21], [6], [7]:

(36a)ΔKi,k=KK(1),

(36b)KK(3)=R˜kTYK(3),

(36c)YK(2)=R˜i−(k+1)TH(2).

Similarly, we evaluate ΔLi,k in (27b) by

(37a)ΔLi,k=KL(2),

(37b)KL(3)=R˜kTYL(3),

(37c)YL(1)=S˜i−(k+1)TH.

References

1. Y. G. I. Acle, F. D. Freitas, N. Martins and J. Rommes. Parameter preserving model order reduction of large sparse small-signal electromechanical stability power system models. IEEE Transactions on Power Systems, 34(4):2814–2824, 2019. 10.1109/TPWRS.2019.2898977.Search in Google Scholar

2. U. M. Al-Saggaf. Reduced-order models for dynamic control of a power plant with an improved transient and steady-state behavior. Electric Power Systems Research, 1993.10.1016/0378-7796(93)90071-LSearch in Google Scholar

3. A. C. Antoulas. Approximation of Large-Scale Dynamical Systems, volume 6 of Adv. Des. Control. SIAM Publications, Philadelphia, PA, 2005. ISBN 9780898715293. 10.1137/1.9780898718713.Search in Google Scholar

4. U. Baur, P. Benner and L. Feng. Model order reduction for linear and nonlinear systems: A system-theoretic perspective. Arch. Comput. Methods Eng., 21(4):331–358, 2014. 10.1007/s11831-014-9111-2.Search in Google Scholar

5. C. Beattie, S. Gugercin and V. Mehrmann. Model reduction for systems with inhomogeneous initial conditions. Syst. Control Lett., 99:99–106, 2017. 10.1016/j.sysconle.2016.11.007.Search in Google Scholar

6. P. Benner and T. Breiten. Two-sided projection methods for nonlinear model order reduction. SIAM J. Sci. Comput., 37(2):B239–B260, 2015. 10.1137/14097255X.Search in Google Scholar

7. P. Benner and P. Goyal. Balanced truncation model order reduction for quadratic-bilinear systems. e-prints arXiv:1705.00160, 2017. math.OC.Search in Google Scholar

8. D. Chaniotis and M. A. Pai. Model reduction in power systems using Krylov subspace methods. IEEE Transactions on Power Systems, 20(2):888–894, 2005. 10.1109/TPWRS.2005.846109.Search in Google Scholar

9. X. Cheng and J. M. A. Scherpen. Clustering approach to model order reduction of power networks with distributed controllers. Advances in Computational Mathematics, 44(6):1917–1939, 2018. 10.1007/s10444-018-9617-5.Search in Google Scholar

10. A. Cherid and M. Bettayeb. Reduced-order models for the dynamics of a single-machine power system via balancing. Electric Power Systems Research, 22(1):7–12, 1991. 10.1016/0378-7796(91)90073-V.Search in Google Scholar

11. J. H. Chow, editor. Power System Coherency and Model Reduction, volume 94. Springer, 2013. 10.1007/978-1-4614-1803-0.Search in Google Scholar

12. J. H. Chow, J. R. Winkelman, M. A. Pai and P. W. Sauer. Singular perturbation analysis of large-scale power systems. International Journal of Electrical Power & Energy Systems, 12(2), 1990. 10.1016/0142-0615(90)90007-X.Search in Google Scholar

13. G. H. Golub and C. F. Van Loan. Matrix Computations. Johns Hopkins Studies in the Mathematical Sciences. Johns Hopkins University Press, Baltimore, fourth edition, 2013. ISBN 978-1-4214-0794-4; 1-4214-0794-9; 978-1-4214-0859-0.10.56021/9781421407944Search in Google Scholar

14. M. Heinkenschloss, T. Reis and A. C. Antoulas. Balanced truncation model reduction for systems with inhomogeneous initial conditions. Automatica J. IFAC, 47(3):559–564, 2011. 10.1016/j.automatica.2010.12.002.Search in Google Scholar

15. N. J. Higham. Computing the polar decomposition—with applications. SIAM J. Sci. Statist. Comput., 7:1160–1174, 1986.10.1137/0907079Search in Google Scholar

16. N. J. Higham. Computing a nearest symmetric positive semidefinite matrix. Linear Algebra Appl., 103:103–118, 1988. ISSN 0024-3795. 10.1016/0024-3795(88)90223-6.Search in Google Scholar

17. J. R. Hockenberry. Evaluation of uncertainty in dynamic reduced-order power system models. PhD thesis, Massachusetts Institute of Technology, 2000.Search in Google Scholar

18. R. A. Horn and C. R. Johnson. Topics in Matrix Analysis. Cambridge University Press, Cambridge, 1991.10.1017/CBO9780511840371Search in Google Scholar

19. S.-K. Joo, C.-C. Liu, L. E. Jones and J.-W. Choe. Coherency and aggregation techniques incorporating rotor and voltage dynamics. IEEE Transactions on Power Systems, 19(2):1068–1075, 2004. 10.1109/TPWRS.2004.825825.Search in Google Scholar

20. M. Khatibi and H. Zargarzadeh. Power system dynamic model reduction by means of an iterative SVD-Krylov model reduction method. In 2016 IEEE Power & Energy Society Innovative Smart Grid Technologies Conference (ISGT), page 16526042, 2016. 10.1109/ISGT.2016.7781027.Search in Google Scholar

21. T. G. Kolda and B. W. Bader. Tensor decompositions and applications. SIAM Rev., 51(3):455–500, 2009. ISSN 0036-1445. 10.1137/07070111X.Search in Google Scholar

22. B. Kramer and K. Willcox. Balanced truncation model reduction for lifted nonlinear systems, 2019. arXiv:1907.12084v1.Search in Google Scholar

23. B. Kramer and K. E. Willcox. Nonlinear model order reduction via lifting transformations and proper orthogonal decomposition. AIAA Journal, 57(6):2297–2307, 2019. 10.2514/1.J057791.Search in Google Scholar

24. B. Kramer and K. E. Willcox. Nonlinear model order reduction via lifting transformations and proper orthogonal decomposition. AIAA Journal, 57(6):2297–2307, 2019. 10.2514/1.J057791.Search in Google Scholar

25. X. Lan, H. Zhao, Y. Wang and Z. Mi. Nonlinear power system model reduction based on empirical Gramians. In 2016 IEEE International Conference on Power System Technology (POWERCON), page 16487940, 2016. 10.1109/POWERCON.2016.7754074.Search in Google Scholar

26. J. Leung, M. Kinnaert, J.-C. Maun and F. Villella. Model reduction of coherent LPV models in power systems. In 2019 IEEE Power & Energy Society General Meeting (PESGM), page 19302246, 2019. 10.1109/PESGM40551.2019.8973651.Search in Google Scholar

27. Y. Levron and J. Belikov. Reduction of power system dynamic models using sparse representations. IEEE Transactions on Power Systems, 32(5):3893–3900, 2017. 10.1109/TPWRS.2017.2648979.Search in Google Scholar

28. M. H. Malik, D. Borzacchiello, F. Chinesta and P. Diez. Reduced order modeling for transient simulation of power systems using tracetory piece-wise linear approximation. Advanced Modeling and Simulation in Engineering Sciences, 3:31, 2016. 10.1186/s40323-016-0084-6.Search in Google Scholar

29. X. Meng, Q. Wang, N. Zhou, S. Xiao and Y. Chi. Multi-time scale model order reduction and stability consistency certification of inverter-interfaced DG system in AC microgrid. Energies, 11(1):254, 2018. 10.3390/en11010254.Search in Google Scholar

30. F. Milano and K. Srivastava. Dynamic REI equivalents for short circuit and transient stability analyses. Electric Power Systems Research, 79(6):878–887, 2009. 10.1016/j.epsr.2008.11.007.Search in Google Scholar

31. P. Mlinarić, T. Ishizaki, A. Chakrabortty, S. Grundel, P. Benner and J.-i. Imura. Synchronization and aggregation of nonlinear power systems with consideration of bus network structures. In 2018 European Control Conference (ECC), pages 2266–2271, 2018. 10.23919/ECC.2018.8550528.Search in Google Scholar

32. T. Nishikawa and A. E. Motter. Comparative analysis of existing models for power-grid synchronization. New J. Phys., 17:015012, Jan. 2015. 10.1088/1367-2630/17/1/015012.Search in Google Scholar

33. D. Osipov and K. Sun. Adaptive nonlinear model reduction for fast power system simulation. IEEE Transactions on Power Systems, 33(6):6746–6754, 2018. 10.1109/TPWRS.2018.2835766.Search in Google Scholar

34. D. Osipov, N. Duan, A. Dimitrovski, S. Allu, S. Simunovic and K. Sun. Adaptive model reduction for parareal in time method for transient stability simulations. In 2018 IEEE Power & Energy Society General Meeting (PESGM), 2018.10.1109/PESGM.2018.8585841Search in Google Scholar

35. M. A. Pai and R. P. Adgaonkar. Singular perturbation analysis of nonlinear transients in power systems. In 1981 20th IEEE Conference on Decision and Control including the Symposium on Adaptive Processes, pages 221–222, 1981. 10.1109/CDC.1981.269515.Search in Google Scholar

36. B. Parang, M. Mohammadi and M. M. Arefi. Residualisation-based model order reduction in power networks with penetration of photovoltaic resources. IET Generation, Transmission & Distribution, 13(13):2619–2626, 2019. 10.1049/iet-gtd.2018.6172.Search in Google Scholar

37. P. A. Parrilo, S. Lall, F. Paganini, G. C. Verghese, B. C. Lesieutre and J. E. Marsden. Model reduction for analysis of cascading failures in power systems. In 1999 American Control Conference (ACC), 1999. 10.1109/ACC.1999.786351.Search in Google Scholar

38. E. Purvine, E. Cotilla-Sanchez, M. Halappanavar, Z. Huang, G. Lin, S. Lu and S. Wang. Comparative study of clustering techniques for real-time dynamic model reduction. Statistical Analysis and Data Mining, 10(5):263–276, 2017. 10.1002/sam.11352.Search in Google Scholar

39. A. Ramirez, A. Mehrizi-Sani, D. Hussein, M. Matar, M. Abdel-Rahman, J. J. Chavez, A. Davoudi and S. Kamalasadan. Application of balanced realizations for model-order reduction of dynamic power system equivalents. IEEE Transactions on Power Delivery, 31(5):2304–2312, 2016. 10.1109/TPWRD.2015.2496498.Search in Google Scholar

40. H. Rudnick, R. I. Patino and A. Brameller. Power-system dynamic equivalents: coherency recognition via the rate of change of kinetic energy. IEE Proceedings C – Generation, Transmission and Distribution, 128(6):325–333, 1981. 10.1049/ip-c.1981.0052.Search in Google Scholar

41. J. J. Sanchez-Gasca, J. H. Chow and R. Galarza. Reduction of linearized power systems for the study of interarea oscillations. In International Conference on Control Applications (CCA), page 5119382, 1995. 10.1109/CCA.1995.555806.Search in Google Scholar

42. G. Scarciotti. Model reduction of power systems with preservation of slow and poorly damped modes. In 2015 IEEE Power & Energy Society General Meeting, page 15502166, 2015. 10.1109/PESGM.2015.7285719.Search in Google Scholar

43. W. H. A. Schilders, H. A. van der Vorst and J. Rommes. Model Order Reduction: Theory, Research Aspects and Applications. Springer-Verlag, Berlin, Heidelberg, 2008.10.1007/978-3-540-78841-6Search in Google Scholar

44. C. Schröder and M. Voigt. Balanced truncation model reduction with a priori error bounds for LTI systems with nonzero initial value. e-print arXiv:2006.02495v1, 2020. eess.SY.Search in Google Scholar

45. K. Shomalzadeh and T. Amraee. Unstable power system model reduction using balanced truncation. In 2017 25th Iranian Conference on Electrical Engineering (ICEE), page 17045511, 2017. 10.1109/IranianCEE.2017.7985241.Search in Google Scholar

46. C. Sturk. Structured model reduction and its application to power systems. PhD thesis, KTH Royal Institute of Technology, 2012.Search in Google Scholar

47. C. Sturk, L. Vanfretti, Y. Chompoobutrgool and H. Sandberg. Structured power system model reduction of non-coherent areas. In 2012 IEEE Power and Energy Society General Meeting (PESGM), page 13170255, 2012. 10.1109/PESGM.2012.6344913.Search in Google Scholar

48. C. Sturk, L. Vanfretti, F. Milano and H. Sandberg. Structured model reduction of power systems. In 2012 American Control Conference (ACC), pages 2276–2282, 2012. 10.1109/ACC.2012.6315207.Search in Google Scholar

49. C. Sturk, L. Vanfretti, Y. Chompoobutrgool and H. Sandberg. Coherency-independent structured model reduction of power systems. IEEE Transactions on Power Systems, 29(5):2418–2426, 2014. 10.1109/TPWRS.2014.2302871.Search in Google Scholar

50. C. F. Van Loan. The ubiquitous Kronecker product. J. Comput. Appl. Math., 123(1-2):85–100, 2000. 10.1016/S0377-0427(00)00393-9. Special Issue: Numerical analysis 2000, Vol. III. Linear algebra.Search in Google Scholar

51. C. Wang, H. Yu, P. Li, C. Ding, C. Sun, X. Guo, F. Zhang, Y. Zhou and Z. Yu. Krylov subspace based model reduction method for transient simulation of active distribution grid. In 2013 IEEE Power & Energy Society General Meeting, page 13933173, 2013. 10.1109/PESMG.2013.6672277.Search in Google Scholar

52. C. Wang, H. Yu, P. Li, J. Wu and C. Ding. Model order reduction for transient simulation of active distribution networks. IET Generation, Transmission & Distribution, 9(5), 2015. 10.1049/iet-gtd.2014.0219.Search in Google Scholar

53. S. Wang, S. Lu, N. Zhou, G. Lin, M. Elizondo and M. A. Pai. Dynamic-feature extraction, attribution, and reconstruction (DEAR) method for power system model reduction. IEEE Transactions on Power Systems, 29(5):2049–2059, 2014. 10.1109/TPWRS.2014.2301032.Search in Google Scholar

54. S.-C. Wang, P.-H. Huang and C.-J. Wu. Application of fuzzy C-means clustering in power system model reduction for controller design. In 5th WSEAS International Conference on Computational Intelligence, Man-machine systems and Cybernetics, pages 223–227, 2006.Search in Google Scholar

55. H. Weber and E. Welfonder. Dynamic model reduction for the modal analysis of frequency and power oscillations in large power systems. IFAC Proceedings Volumes, 21(11):233–239, 1988. 10.1016/S1474-6670(17)53749-0.Search in Google Scholar

56. F. Weiß. Simulation, analysis, and model order reduction for dynamic power network models. Master’s thesis, Otto-von-Guericke-Universität Magdeburg, 2019.Search in Google Scholar

57. H. Zhao, X. Lan and H. Ren. Nonlinear power system model reduction based on empirical Gramians. Journal of Electrical Engineering, 68(6):425–434, 2017. 10.1515/jee-2017-0077.Search in Google Scholar

58. H.-S. Zhao, N. Xue and N. Shi. Nonlinear dynamic power system model reduction analysis using balanced empirical Gramian. Applied Mechanics and Materials, 448–453:2368–2374, 2013. 10.4028/www.scientific.net/AMM.448-453.2368.Search in Google Scholar

59. Z. Zhu, G. Geng and Q. Jiang. Power system dynamic model reduction based on extended Krylov subspace method. IEEE Transactions on Power Systems, 31(6):4483–4494, 2016. 10.1109/TPWRS.2015.2509481.Search in Google Scholar

60. R. D. Zimmerman and C. E. Murillo-Sánchez. MATPOWER (version 6.0), 2016.Search in Google Scholar

61. R. D. Zimmerman, C. E. Murillo-Sánchez and R. J. Thomas. MATPOWER: Steady-state operations, planning, and analysis tools for power systems research and education. IEEE Transactions on Power Systems, 26(1):12–19, 2011. 10.1109/TPWRS.2010.2051168.Search in Google Scholar
