Startseite The crystal structure of di(thiocyanato-κ1N)-bis(methanol)-di(1,3-bis((pyridin-4-ylthio)methyl)benzene)-iron(II), C40H40FeN6O2S6
Artikel Open Access

The crystal structure of di(thiocyanato-κ1N)-bis(methanol)-di(1,3-bis((pyridin-4-ylthio)methyl)benzene)-iron(II), C40H40FeN6O2S6

  • Qi Liu und Haitian Yu EMAIL logo
Veröffentlicht/Copyright: 1. Mai 2025
Artikel downloaden (PDF)
Veröffentlichen auch Sie bei De Gruyter Brill
Manuskript einreichen Informationen für Autor*innen
Zeitschrift für Kristallographie - New Crystal Structures
Aus der Zeitschrift Zeitschrift für Kristallographie - New Crystal Structures Band 240 Heft 4

Abstract

C40H40FeN6O2S6, monoclinic, P21/n (no. 14), a = 9.0820(3) Å, b = 17.1717(6) Å, c = 13.0782(5) Å, β = 99.022(4)°, V = 2014.36 Å3, Z = 2, R gt (F) = 0.0348, wR ref(F 2) = 0.0844, T = 293 K.

CCDC no.: 2442646

The molecular structure is shown in the Figure and Table 1 contains crystallographic data.

1 Source of materials

The ligand 1,3-bis((pyridin-4-ylthio)methyl)benzene (L1) was prepared by following the reported literature method. 1 A solution of ligand L1 (6.28 mg, 0.2 mmol) in methanol (5 mL) was added dropwise under stirring to a methanolic solution (10 mL) containing FeCl2 (12.7 mg, 0.10 mmol) and KSCN (19.4 mg, 0.2 mmol). The formed solution was stirred for 1–2 min followed by filtering and the filterate was allowed to slowly evaporate in air at room temperature. Block brown crystals appeared after about one week, which were collected and air-dried. Yield: 46.9 mg (53.1 %).

Table 1:

Data collection and handling.

Crystal: Brown block
Size: 0.15 × 0.11 × 0.09 mm
Wavelength: Mo Kα radiation (0.71073 Å)
μ: 0.73 mm−1
Diffractometer, scan mode: Bruker APEX II, φ and ω scans
θ max, completeness: 25.0°, 100 %
N(hkl)measured, N(hkl)unique, R int: 6580, 3532, 0.022
Criterion for I obs, N(hkl)gt: I obs > 2σ(I obs), 2,976
N(param)refined: 251
Programs: Bruker, 2 SHELX 3 , 4

2 Experimental details

Coordinates of hydrogen atoms bonded to the C atoms were refined with constraints or restraints. Their U iso values were set to 1.2 U eq or 1.5 U eq of the parent atoms. For the H atom of the coordinated methanol molecule, it was refined isotropically with fixed U values, and the DFIX command was used to rationalize the bond parameter.

3 Comment

In recent years, due to the various important potential applications in magnetic devices, spin crossover (SCO) complexes 5 , 6 with distinctive characteristic of the controlled switching between high spin state (HS) and low spin state (LS), have always been an important research topic in molecule magnetism field. As has been displayed in many previous reports, iron(II) ions with d6 electron configurations could switch between paramagnetic HS and dimagnetic LS through external stimuli such as temperature, pressure, light, electricity, or light radiation. 7 , 8 , 9 , 10 Here, we report the structure of a new Fe(II) complex based on a semi-rigid V-shaped bidentate ligand 1,3-bis((pyridin-4-ylthio)methyl)benzene (L1).

As presented in the figure, the title neutral Fe(II) complex [Fe(L1)2(CH3OH)2(NCS)2] crystallizes in the monoclinic space group P21/n. The Fe(II) ion in title complex is involved in a hexa-coordinated octahedron surrounding, in which the six coordinate sites with mutual trans positions were occupied by two N atoms of 1,3-bis((pyridin-4-ylthio)methyl)benzene acting as terminal monodentate ligand, the O atoms of the two methanol molecules and the two N atoms of the thiocyanato ions, respectively. The Fe–N L 1, Fe–NNCS and Fe–Omethanol bond lengths are 2.1886(19), 2.130(2) and 2.1348(16) Å, respectively, showing the slightly distorted octahedral coordination sphere of the central Fe(II) ion and implying the high spin state nature of the Fe(II) ion in this complex. The Fe–NC bond angle is 171.1(2)°, indicating the almost linear configuration of these three atoms. Under the help of the intermolecular O–H⃛N hydrogen bond interactions between the O atom of the methanol molecule and the uncoordinated N atom of the ligand L1, the title complex could be further linked into two-dimensional supramolecular network structure.

Corresponding author: Haitian Yu, Department of Ecology and Environmental Protection, Linyi Vocational University of Science and Technology, Linyi, 276025, P. R. China, E-mail:

Funding source: Linyi Vocational University of Science and Technology

  1. Research funding: This work was supported by the university-level research project funding from Linyi Vocational University of Science and Technology.

References

1. Xu, Z. J.; Meng, S.; Cao, T.; Xin, Y.; Wang, C. Y.; Hao, H. G.; Yang, L.; Zhou, Z.; Zhang, D. P. Substituent Group Tuned Structural Dimensionalities and Magnetic Properties of V-Shaped Bis-Pyridyl Ligands Based Fe(II) Coordination Polymers. J. Mol. Struct. 2024, 1296, 136866; https://doi.org/10.1016/j.molstruc.2023.136866.Suche in Google Scholar

2. Bruker. Apex2, Saint–Plus, Xprep; Bruker AXS Inc.: Madison, Wisconsin, USA, 2004.Suche in Google Scholar

3. Sheldrick, G. M. Shelxt – Integrated Space-Group and Crystal-Structure Determination. Acta Crystallogr. 2015, A71, 3–8; https://doi.org/10.1107/s2053273314026370.Suche in Google Scholar PubMed PubMed Central

4. Sheldrick, G. M. Crystal Structure Refinement with Shelxl. Acta Crystallogr. 2015, C71, 3–8; https://doi.org/10.1107/s2053229614024218.Suche in Google Scholar PubMed PubMed Central

5. Diaz–Torres, R.; Boonprab, T.; Gómez–Coca, S.; Ruiz, E.; Harding, P.; Harding, D. J. Structural and Theoretical Insights into Solvent Effects in an Iron(III) SCO Complex. Inorg. Chem. Front. 2022, 9, 5317–5326; https://doi.org/10.1039/d2qi01159j.Suche in Google Scholar

6. Qin, C. Y.; Zhao, S. Z.; Wu, H. Y.; Li, Y. H.; Wang, Z. K.; Wang, Z.; Wang, S. The Dynamic Interplay between Intramolecular and Intermolecular Interactions in Mononuclear Manganese (III) SCO Complexes. Dalton Trans. 2021, 50, 5899–5910; https://doi.org/10.1039/d0dt04109b.Suche in Google Scholar PubMed

7. Chen, X. Q.; Cai, Y. D.; Jiang, W.; Peng, G.; Feng, J. K.; Liu, J. L.; Tong, M. L.; Bao, X. A Multi-Stimuli-Responsive Fe(II) SCO Complex Based on an Acylhydrazone Ligand. Inorg. Chem. 2019, 58, 999–1002; https://doi.org/10.1021/acs.inorgchem.8b02922.Suche in Google Scholar PubMed

8. Kumar, K. S.; Salitros, I.; Heinrich, B.; Fuhr, O.; Ruben, M. A Charge Neutral Iron(II) Complex with an above Room Temperature Spin Crossover (SCO) and Hysteresis Loop. J. Mater. Chem. C 2015, 3, 11635–11644; https://doi.org/10.1039/c5tc02079d.Suche in Google Scholar

9. Luo, Y. H.; Nihei, M.; Wen, G. J.; Sun, B. W.; Oshio, H. Ambient-temperature Spin-State Switching Achieved by Protonation of the Amino Group in [Fe(H2Bpz2)2 (bipy–NH2)]. Inorg. Chem. 2016, 55, 8147–8152; https://doi.org/10.1021/acs.inorgchem.6b01193.Suche in Google Scholar PubMed

10. Shepherd, H. J.; Rosa, P.; Vendier, L.; Casati, N.; Létard, J. F.; Bousseksou, A.; Guionneau, P.; Moln’ar, G. High-pressure Spin-Crossover in a Dinuclear Fe(II) Complex. Phys. Chem. Chem. Phys. 2012, 14, 5265–5271; https://doi.org/10.1039/c2cp23940j.Suche in Google Scholar PubMed

Received: 2025-01-23
Accepted: 2025-04-10
Published Online: 2025-05-01
Published in Print: 2025-08-26

© 2025 the author(s), published by De Gruyter, Berlin/Boston

This work is licensed under the Creative Commons Attribution 4.0 International License.
